Low Torque 2500rpm Servo Motor

Low Torque 2500rpm Servo Motor thumbnail-1
Low Torque 2500rpm Servo Motor thumbnail-2
Low Torque 2500rpm Servo Motor thumbnail-3
Low Torque 2500rpm Servo Motor photo-1
Low Torque 2500rpm Servo Motor photo-2
Low Torque 2500rpm Servo Motor photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Maxsine
Model Number:
80MSL04025F
Type:
Servo Motor
Contact Supplier Request Quote Chat Now
Wuhan Maxsine Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Maxsine
Model Number 80MSL04025F
Type Servo Motor
Frequency 50hz
Output Power 1000W
Protect Feature Waterproof
Phase Three-phase
Certification CE, Other, CE, ISO, TUV
AC Voltage 208-230 / 240 V
Place of Origin Hubei, China
Efficiency IE 3

Specifications

1' 220V AC 50hz 3 phase
2' 2500 ppr TAMAGAWA incremental encoder
3' rated power 1000w
4' 2500rpm, 4nm
5' CE, ISO, TUV

Production Description
Low torque 2500rpm servo motor
  • 2500PPR Incremental encoder
  • 1000W
  • Wide adjustable speed range
  • Protection Level: IP65
Name Low torque 2500rpm servo motor
Motor Model 80MSL04025F
Input Power 3-phase AC220V 50/60Hz
Rated Power 1000W
Rated Line Voltage 220V
Rated Line Current 4.4A
Rated Speed 3000rpm
Rated Torque 4Nm
Peak Torque 12Nm
Rotor Inertia 3.5*10-4kgm2
Weight 3.8kg
Encoder Incremental encoder
Lines of Encoder 2500PPR
Motor Insulation Class ClassB(130°C)
Protection Level IP65
Operating Environment Temperature:-20°C ~ +50°C; humidity:relative humidity (RH)<90%(not including condensing condition)



Details show



Low torque 2500rpm servo motor

Application

1. CNC industry

2. Textile industry

3. Printing and packaging industry

4. Robot industry

5. Mechanical spring machine industry

6. Paper making industry

7. Industrial spring machine


Shipping

1. EXPRESS(sample): around 5-7 working days to arrive

2. EXPRESS: around 3 weeks to arrive

3. Ocean carriage: usually less than 2 months

Payment

1. Wire Transfer

2. West Union

3. Paypal

Certification
                Low torque 2500rpm servo motor
Packing
After inspection the goods are packed in plastic bags and then carefully packed in cartons.

Low torque 2500rpm servo motor

Services

Low torque 2500rpm servo motor

About us

Wuhan Maxsine Electric Co., Ltd.was established in Wuhan in 2004. Alldigital AC Servo Drivers and

Permanent Magnet AC Servo Motors are core products. They have been chosen and approved by more and more customers and been widely used in the numerical control machine tool, textile machinery, packaging machine, printing machine, cutting machine, marking machine, industrial robot and many other industrial automation fields.
