Home > Electrical & Electronics > Variable-Frequency Drive > Modbus Communication ac Servo Motor Controller

Modbus Communication ac Servo Motor Controller

Name: Modbus Communication ac Servo Motor Controller
Brand: Maxsine
SKU: 118969945
Availability: InStock

Modbus Communication ac Servo Motor Controller thumbnail-1

Modbus Communication ac Servo Motor Controller photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Hubei, China

Brand Name:

Maxsine

Model Number:

EP3-GL160F

Contact Supplier Request Quote Chat Now

Wuhan Maxsine Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hubei, China

Brand Name Maxsine

Model Number EP3-GL160F

Motor Type AC Motor

Specifications

1' 220V AC 50hz 3 phase
2' Pulse and analog control
3' rated power 2.0kw
4' USB interface, MODBUS
5' CE, ISO, TUV

Production Description

All-digital AC Servo Driver: currently covers power range from 50w to 5.5kw

Permanent Magnet AC Servo Motor: currently covers torque from 0.6 Nm to
48 Nm and power from 50w to 7.2kw.

220v ac servomotor speed controller passed CE

Model

1A0

GL 1A8

GL 3A0

GL 7A5

GL 120

GL 160

GL 190

GL 240

3A5

GH 5A4

GH 8A5

GH 130

GH 170

Rated Output Power(KW)

0.1

0.2

0.4

1.0

1.5

2.0

3.0

5.0

1.0

1.5

2.0

3.0

5.0

Rated Output Current(A)

1.0

1.8

3.0

7.5

12.0

16.0

19.0

24.0

3.5

5.4

8.5

13.0

17.0

Input Power

Main Supply

1-phase 220VAC -15%~+10% 50/60Hz

3-phase 220VAC

-15%+10% 50/60Hz

3-phase 380VAC

-15%~+10% 50/60Hz

Control Supply

1-phase 220VAC-15%~+10% 50/60Hz

24VDC±15% not less than 1.5A

Environment

Temperature

Working:0 ~ 40°C Storing:-40 ~ 50°C

Humidity

Working:40% ~ 80%(non condensing) Storing:93% below(non condensing)

Atmospheric Pressure

86kPa ~ 106 kPa

Protection Level

IP20

Control Mode

Vector Control

Regenerative Braking

Built-in/built-out

Built-out

Feedback Mode

2500 line incremental encoder or 17 bit absolute encoder

Control Mode

Position, Speed, Torque, Position/ Speed,Speed/Torque,Position/Torque

Digital Input

5 Programmable Input Terminals(Optical Isolation)

Digital Output

3 Programmable Input Terminals(Optical Isolation)

Signal Output of Encoder

SignalTypes

A,B,Z Differential Output,Z signal open-collector output

Poles

Programmable Fractional Frequency(using Incremental Coder)/1~131072P/R(using

Absolute Encoder)

Position

Input Frequency

differential input:≤500kHz(kpps);

single-ended input:≤200kHz(kpps)

Instruction Mode

Pulse+Signal,CCW Pulse/CW Pulse, Two-phase A/ orthogonal Pulse

Electronic Gear Ratio

1~32767/1 ~ 32767

Speed

Simulation Command Input

±10VDC,Input Impedance 10kΩ

Instructions Acceleration and Deceleration

Parameters Set

Instructions Source

Analog,Internal Speed Instructions

Torque

Simulation Command Input

-10V ~ +10V,Input Impedance 10kΩ

Torque Restriction

Parameters Set

Instructions Source

Analog,Internal Speed Instructions

Special Functions

ZRN ,Gain Switch,Mechanical Resonance Wave Trap, Sustaining Modbus Agreement

Surveillance Function

Revolving Speed,Current Position,Positional Deviation,Motor Torque,Motor Current,

Instructions Pulse Frequency etc.

Defensive Function

Overspeed,Overvoltage,

Overcurrent,Overload,Abnormal Brake,Abnormal Encoder,Out of tolerance etc.

Feature

Speed Frequency Response

≥300Hz

Speed Fluctuation Rate

<±0.03%(load 0~100%); <±0.02%(power -15% ~ +10%)

Speed Ratio

1:5000

Details show

Application

CNC industry
Textile industry
Robot industry
Paper making industry
Industrial spring machine
Printing and packaging industry
Mechanical spring machine industry

Shipping

EXPRESS(sample): around 5-7 working days to arrive
EXPRESS: around 3 weeks to arrive
Ocean carriage: usually less than 2 months

Payment

Wire Transfer
Western Union
Paypal

Certification

Packing

After inspection the goods are packed in plastic bags and then carefully packed in cartons.

Services

About us and exhibition

Wuhan Maxsine Electric Co., Ltd.was established in Wuhan in 2004. Alldigital AC Servo Drivers and Permanent Magnet AC Servo Motors are core products. They have been chosen and approved by more and more customers and been widely used in the numerical control machine tool, textile machinery, packaging machine, printing machine, cutting machine, marking machine, industrial robot and many other industrial automation fields.
