Specifications
1' 220V AC 50hz 3 phase2' Pulse control
3' rated power 1.0kw
4' USB interface
5' CE, ISO, TUV
Position control ac servo amplifier 1000watt
About us
All-digital AC servo motor motion control driver and servo motor have been researched for 20 year and been produced for 10 years by us. It is believed that good quality products and service could be offered for you.
About this product
A.Introduction
EP1C series AC Servo Driver adopts advanced control algorithm and intelligent power module (IPM), which could realize precise digital control on position. Designed on the basis of EP1 series, functions of external brake resistor , DC Reactor terminals and USB communication interfaces are added. As a result, power section has become more comp-lement whose range is from 500W to 5.5kW at present.
B.New function
a. Position control mode
b. 5 Programmable input terminals(Optical Isolation) Function
c. 3 Programmable output terminals(Optical Isolation) Function
d. Defensive function
e. Surveillance Function
C. Features
a. only position control
b. low cost
c. Simply maintenance
D. Scope of application
a. CNC industry
b. Textile industry
c. Printing and packaging industry
d. Robot industry
e. Mechanical spring machine industry
f. Paper making industry
g. Industrial spring machine
E. Main Markets
a. Asia
b. Europe
c. Middle East
d. South America
e. North America
f. Oceania
g. Africa
F. Technical parameters
| Model | TL05F | TL10F | TL15F | TL25F | TL35F | TL55F | ||
| Input Power | 3-phase AC220V -15% ~ +10% 50/60Hz | |||||||
| Environment | Temperature | Working: 0°C ~ 40°C Storing: -40°C ~ 50°C | ||||||
| Humidity | Working:40% ~ 80%(non condensing) Storing:under 93%(non condensing ) | |||||||
| Atmospheric Pressure | 86kPa ~ 106 kPa | |||||||
| Protection Level | IP20 | |||||||
| Control Mode | vector control | |||||||
| Regenerative Braking | Built-in/Built-out | |||||||
| Feedback Mode | 2500 line incremental encoder,encoder with fewer lines | |||||||
| Control Mode | Position | |||||||
| Digital input | 5 Programmable input terminals(Optical Isolation) Function:SRVON ,ACLR ,CW Drive inhibition,CCW Drive inhibition,CW Torque inhibition,CCW Torque inhibition,Emergency Stop,Electronic gear selection 1,electronic gear selection2,Position deviation clear,pulse input inhibition | |||||||
| Digital Output | 3 Programmable output terminals(Optical Isolation) Function:SRDY ,alarm,Finish Orientation Output ,Reach Speed ,electro-magnetic brake,Torque restrictions | |||||||
| Signal Output of encoder | Signal Types | A,B,Z Differential output,Z signal open-collector output | ||||||
| Position | Input Frequency | differential input:≤500kHz(kpps), single-ended input:≤200kHz(kpps) | ||||||
| instruction mode | Pulse+Signal,CCW Pulse/CW Pulse, orthogonal Pulse | |||||||
| Electronic Gear Ratio | 1 ~ 32767/1 ~ 32767 | |||||||
| Surveillance Function | Revolving Speed,Current Position,Positional Deviation,Motor Torque,Motor Current,Instructions Pulse Frequency etc. | |||||||
| Defensive function | Overspeed,Overvoltage,Overcurrent,Overload,Abnormal of main Power,Abnormal Encoder,out of tolerance etc. | |||||||
| Feature | Speed Frequency Response | ≥300Hz | ||||||
| Speed Fluctuation Rate | <±0.03%(load 0 ~ 100%); <±0.02%(power-15% +10%) | |||||||
| Speed Ratio | 3.513888889 | |||||||
G. Certifications
a. Quality Management System Certification
b. HI-tech Enterprise certification
c. Patent for Invention: a kind of device and method of alterable encoder output lines
H. Our favorable Service:
a. The fewest MOQ is offered. You can purchase 1 set for testing before you place a big order. We will send samples by express like DHL or Fedex.
b. A variety of special specifications for customized products could be provided for customers with comprehensive solutions.
c. Welcome to visit our company.
d. For more information about our products,please feel free to contact us by email or telephone. Thank you.
