SRL series plastic high-speed mixer

Specifications

1.type:SRL series plastic high-speed mixer
2.effective volume:360L
3.power:55kw
4.speed:475/950rpm
5.CE certification

SRL series plastic high-speed mixer

1.It is used in mixing, compounding, , drying, coloring and other processing of PVC, PP, PE etc.It is ideal equipment for producing shaped plastic material and plastic pipes.

2.The unit combines heat mixing and cool mixing together

3.The materials after heat mixing will go into the cool mixing for exhausting the remained gas and preventing blocking.

4.Advanced control system ensures the smooth running



 SRL series plastic high-speed mixer technical data:

Model	Total capacity(L)	Effective capacity(L)	Motor power(kw)	Spindle speed(rpm)	Heating method	Discharge method
SRL-Z50/100	50/100	32/75	7/11/5.5	750/1500/180	Self-friction or  Electric   heating	Hand work or  pneumatic
SRL-Z100/200	100/200	75/160	14/22/7.5	650/1300/150
SRL-Z200/500	200/500	150/320	30/42/11	475/950/130
SRL-Z300/600	300/600	200/360	40/55/11	475/950/130
SRL-Z300/1000	300/1000	200/640	40/55/11	475/950/50		Pneumatic
SRL-Z500/1000A	500/1000	375/650	47/67/18.5	430/860/60
SRL-Z500/1000B	500/1000	350/640	55/75/15	430/860/50
SRL-Z500/1600B	500/1600	375/1200	55/75/18.5	430/860/60
SRL-Z800/1600A	800/1600	600/1024	75/30	500/50





Auto loader/feeder:
