Data Collector With 1D Bar code Scanner 2800mAH battery IWSI005
Main Unit |
| |||
Model | OBM-9800 |
| ||
Color | Frosted white |
| ||
CPU speed | 48MHz |
| ||
Memory |
| |||
RAM | 64KB |
| ||
ROM | 16MB (optional 32MB) |
| ||
Screen |
| |||
size | 2.8” |
| ||
color | 16bit true color（65536 colors） |
| ||
resolution | 240*320 TFT |
| ||
Physical |
| |||
Battery | Rechargeable Lithium-ion （3.7V，2800mAh） |
| ||
Working time | 8 hours |
| ||
Standby | 15 days |
| ||
Dimension | 150mm×63mm×31mm |
| ||
| Material | ABS + silicone |
| |
| Charging indicator | LCD |
| |
| Working current | 190mA |
| |
| Standby current | 40mA |
| |
| EMC | CE & FCC DOC compliance |
| |
Scanning |
| |||
| Light Source | 650nm |
| |
| Decode Rate | 100±2 scans / second |
| |
| Resolution | 3mil |
| |
| Scan width | 20mm@window，100mm@100mm |
| |
| Depth of Field | 0～250mm（0.33mm，PCS 90%） |
| |
| indicator | beeper，LCD |
| |
| Barcode supported | EAN-8，EAN-13，UPC-A，UPC-E，Code 39，Code 93，Code 128，EAN128，Codaber，Industoal 2 of 5，Interleave 2 of 5，Matrix 2 of 5，MSI |
| |
Transmission | ||||
cable | USB 2.0 |
| ||
wireless | 433MHz (max. 300m) |
|
| |
Environment |
| |||
| Working Temperature | 0°C～45°C |
|
|
| Storing Temperature | -20°C～60°C |
| |
| Humidity | 5%～95% |
| |
| Lumination | Max.5,000 Lux（Fluorescence） |
| |
