Home > Office Supplies > Scanner > IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner photo-1
US$ 150 - 200 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
CCD
Payment & Shipping
Payment Methods:
Port of Shipment:
gz
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Type Barcode Scanner
Scan Element Type CCD
Colour Depth 42 Bit
Interface Type USB
Max Paper Size Barcode Scanner
Optical Resolution Code39 3mil, PDF417 5mil, PCS45%
Scan Speed 500scans/sec
Brand Name ISSYZONEPOS
Model Number IOBC020
Place of Origin Guangdong, China

  >
Product Description



IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

Feature
1.Ergonomic design;
2.Convenient and easy to use;
3.Multiply built-in interface,USB/KB/RS232 interface for choice;
4.Fast and accurately decode all standard 1D bar codes;
5.Good anti-shock performance;
6.Suitable for supermarket, mall, shop, post office, warehouse etc use.
Physical Parameters
Material ABS+PC
Size L*W*H 150mm*143mm*82mm
Power Supply DC 5V/2A
Weight 500±5g (without cable)
Performance Parameters
Support Interface USB, USB virtual serial port
Sensor Planar CMOS sensor
Light Source Red LED (aim)+white LED (lighting)
Processor 32 bit ARM MCU+DSP
Decoding Capability

Codabar, Code39, Code32, InterLeaved 2 of 5 (14CHARS), Industrial 2 of 5,

Matrix 2 of 5, Code93, Code128, Gs1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13,

ISSN, GS1 DATABAR(RSS14), GS1 DATABAR Limited, Gs1databar Expanded

Resolution Code39 3mil, PDF417 5mil, PCS45%
Depth of Field 5MIL CODE39: 3--11 CM
13MIL UPC-A : 4--27 CM
20MIL CODE39 : 7.5--35 CM
6.7MIL PDF417 : 3.5--9 CM
10MIL DATAMATRIX: 3--10 CM
15MIL DATAMATRIX: 3--17 CM
Scanning Speed 500scans/sec
Scanning Method Auto-sensing
Scanning Area 5 * 5 cm² -- 30 * 30 cm²
Prompting Mode Buzzer, indicator light(LED)
Printing Contrast No lower than 35%
Scanning Angle Roll 0-360°, pitch ±65°, yaw ±60°
Environment Parameters
IP Grade IP 54
Operating Temperature 0 to 50 ºC / 32 to 122 ºF
Storage Temperature 0 to 50 ºC / 32 to 122 ºF
Operating Humidity 5 - 95% (non-condensing )
ESD Protection 15kv air discharge
Shock Resistance 1m free fall on concrete surface




  >
Trading Process

 IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner


  >

Application Fields



  IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

  >
Certificate

 IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

  >
Payment method


IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

  >
The photos of Packaging




  IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner
    IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

  >
Our Factory


IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

  >
Production Process


 IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

  >
FAQ




1.Do you have the items in stock?
The most of products are in stock. We can send the goods out within 3 days after payment received. For the goods are out of stock, production time is about 7-10 days.

2.Do you offer other relevant items?
Yes we do. We are offering barcode scanner, receipt printer,magnetic card reader and data collector and Pos system.

3.If the goods are damaged badly, who is responsible for it?
We will be responsible for the damaged goods when it is damaged during transport, and we can exchange the new goods for you.

4. How do I know that you have sent the products out?
Once the prodcuts are sent out, a tracking number will be provided so that you can check where your goods at all times.


  >
Company Information




Our Mission is to maximize The Value of Made In China.
Welcome to . We are a supplier mainly provide POS system. Main products: barcode scanner, receipt printer, magnetic card reader and data collector.


Our history:
In 2010, Issyzone was built in Guangzhou.
At that time, we were just a small team of two people.
But now, we have developed to thirty people due to our sales development by five years’ endeavor.


Our products:
In 2010, we started our market of barcode scanner.
In 2012, we broadened our product range by introducing POS system.
We believe that we will have high quality electric products in the future. We still provide high quality service and good quality products for our customers.


Our commitment:
7 days no reason to return
We provide the “7 days no reason return” service, in order to make sure our customers to have a happy transaction. You can return your products without any reason.
We have aftermarket and original parts. All of products are tested and then sent to you. If you have any trouble in using, we are glad to help you solve the problem.


Our aim:

Issyzone, make your business easy!



Our staff:
IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner


  >
Our Services










IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner

IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner   IOBC020 USB Hight Scanning Speed Desktop Omnidirectional 1D Image Barcode Scanner
