QX-1290(130w) Laser Cutter With 2 Heads

US$ 4,600 - 5,800 MOQ: 1 Set

Key Specifications

Condition:

New

Laser Type:

CO2

Applicable Material:

Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Rubber, Stone, Wood

Jinan Quanxing Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Laser Type CO2

Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Rubber, Stone, Wood

Cutting Thickness 1-35mm

Cutting Area 120x90 cm

Cutting Speed 0-400mm/s

CNC or Not Yes

Cooling Mode Water Cooling

Control Software DSP

Graphic Format Supported AI, BMP, DST, DXF, DXP, PLT

Place of Origin Shandong, China

Brand Name QX

Model Number 1290

Certification CE, ISO, SGS

After-sales Service Provided Engineers available to service machinery overseas

QX1290(130w) LASER CUTTER with TWO HEADS

It caters to the customer in the field of clothing, cutting accessories, making holes, leather, embroedery with computer .

main features:

(1) Two laser heads and two laser tubes working simultaneously, which makes processing efficiency ddoubled

(2) cost saving and cutting well-proportioned

(3) used when offine and laser intensity can be controlled sseparately

specification :

Specification
Model	QX1290
Working area	1200*900mm
Laser Power	130W(optional: 60w, 80w, 130w 150w)
Laser Type	CO2 sealed glass Laser Tube
Engraving speed	0-1,000mm/min
Cutting speed	0-500mm/min
Driving system	stepper
Resetting positioning accuracy	0.01mm
Location precision	≤0.01mm
Minimum Shaping Character	1×1mm
Power supply	220V±10% 50HZ or 110V±10% 60HZ
Software supported	ArtCut, CorelDraw, PhotoShop, AutoCAD
Graphic format supported	BMP CIF JPEG TGA TIFF PLT AL DXF DST(TIANDAO Embroidery Software) DWG CDR
Water Cooling(Yes / No)	Yes
Laser Tube (life hours)	3500-4000 hours
Assistant Equipment	Water pump	Air pump	Exhaust fan
Optional Parts	Red dot pointer, auto focus	Water chiller	Rotary, up and down table
Consumables	Lens and mirror, laser tube
Certificate	CE
Proper Materials: Acrylic, Crystal, Bamboo, Cloth, Fabric/Denim, Fiberglass, Glass, Laminated Plastic, Leather, Marble, Plastic, Paper, Rubber, Wood, MDF, Marble, Anodized Aluminium, Coated Metal, etc.
Application: Sign Making, Nameplates, Awards, Badges and Tags, Gift Engraving, Model Making, Architectural Model, Image engraving, Fabric Engraving and Cutting, Jeans Image, Hollowing on Leather, Notary Seals, Rubber Stamps, Souvenirs, etc.
Warranty: 12 Months for Machine 3 months for laser tube, lens and mirrors 6 months for external assistant device, such as water pump, fan
