Auto Recognize F&NF Probe Car Paint Coating Thickness Test Tool

PLN-CT2013FN(update type)
Coating thickness gauge ( Dry film Thickness gauge)
The type CT2013FN film thickness gauge allows for measurement of a variety of products.
It is built in both of FE and NFE Probe in one gauge,and could recognized the substrate
automatic.
A. Large LCD display with background light and could have different background color for
choose
B. Zero point calibration and Multi-point calibration;
C. User can recall 20 Store data, delete specified readings, or delete group readings;
D. Statistics display: Average, minimum, maximum data;
E. Built in both of FE and NFE probe
F. Power off automatically;
G. Low battery and error indication;
H. Signal hand operate, simple key and easy operate
I. 180 degrees flip to read data
J. V-shaped grooves suitable measurement on the cylindrical parts
K. Special probe tip structure with more better stability
L. Voice Reminder of operate

Technical Specifications
Substrate :Fe steel or iron
Substrate NFe non-magnetic metals: aluminum, copper, brass, zinc,
stainless steel
Measuring Range Fe: 0 - 1500 µm (0 - 60 mils)
NFe: 0 - 1500 µm (0 - 60 mils)
Resolution :0.1um (0-99um);1um (100-1500um)
Accuracy :±(1.8%um±2um)(0-500um);±(2.2%um±2um) (500-1500um)
Repeatability and Reproducibility study :±1um 0-500um;±2um 500-1500um
Minimum Substrate Thickness Fe: 0.2 mm , NFe 0,05 mm
MinimumArea of Measurement : convexity 5mm concave : 30mm
Operating Temperature :-10 - 60 °C
Use temperature : 0-50°C
Humidity :<80%
Power Supply :2 x AABatteries
Dimensions :120mmx52mmx25mm
Weight approx. 72 g without battery, with battary of 100g

Basic Functions:
1. Auto recognize the substrate of Ferrous or Non-Ferrous

2.Auto switch on by place the the probe on a surface

3.With automatic shutdown function

4. Flip display

5. Metric/imperial system selectable

6.Store up to 20 of the latest data, analyzed the MAX. MIN. AVG.

7.Historical data are clearable, restore factory settings

8.Three different calibration, Zero Calibration,Two Point Calibration and Multi-point calibration

9.LCD Backlight

10.Low voltage indicator

Package:  Now there are 2 types of regular package:

(1) 1 complete set of gauge package: 1 pcs gauge, 1 set calibration, 1 instruction, 1 black glasses box.

 (2) 5 complete sets of gauge package: 5 pcs gauge, 5 sets calibration, 5 instructions, 5 black glasses boxes, 1 white carton box whose outside is with the color cover.
