Specifications
Quality Electronic Ballasts1)Voltage:100-268VAC
2)Input frequency:50/60Hz
3)Power factor>0.99
4)400W/600W/1000W
400W/600W/1000W HPS/MH Dimming / Dimmable Electronic Ballasts
ROSH,FCC, CE, TUV, UL certification approved
Features:
1) Outstanding energy-saving effect
A) Low power loss
B) High power factor
C) High lighting efficiency
2) Perfect protection and monitoring function
A) Built-in voltage monitoring function
B) Trouble-detecting protection function
3) Dimming, adjustable output power
4) Light weight, small size, non-flickering, noiseless
5) Fast start-up, reach full brightness quickly
6) Operate HPS & MH lamps.
7) Available in 220-240V and 110-120V, 150W/250W400W/600W/1000W
8) Come with a 8ft power cord
9) Year factory warranty
| Outside Dimension | 248*112*74mm | 316*112*74mm | 391*112*74mm |
| Material of Housing | Aluminum | Aluminum | Aluminum |
| Ambient Operating Temp | –30~+55 Celsius Degree | –30~+55 Celsius Degree | –30~+55 Celsius Degree |
| Max Lamp Distance from Ballast | ≤15 Meters | ≤15 Meters | ≤15 Meters |
| Max Enclosure Temp | 90 Celsius Degree | 90 Celsius Degree | 90 Celsius Degree |
| Input Voltage | 100-268VAC | 100-268VAC | 100-265AC |
| Input Frequency | 50Hz~60Hz | 50Hz~60Hz | 50Hz~60Hz |
| Rated Input Voltage | 220VAC110VAC | 220VAC110VAC | 220VAC110VAC |
| Power Factor | 0.99 | 0.99 | 0.99 |
| THD | <10% | <10% | <10% |
| Output Power | 400W±5% | 600W±5% | 1000W±5% |
| Output Frequency | >30KHz | >30KHz | >30KHz |
| Diming Function |
Manual Diming High-Medium-Low |
Manual Diming High-Medium-Low |
Manual Diming High-Medium-Low |
| Short Circuit Protection | Yes | Yes | Yes |
| Open Circuit Protection | Yes | Yes | Yes |
| Light-off Failture Protection | Yes | Yes | Yes |
| Thermal Protaction | Yes | Yes | Yes |
| Lamp Failture Protection | Yes | Yes | Yes |
Advantage:
small size, light weight, low operating temperature, rapid install and excellent energy saving.
