Home > Products > Power mixer > 2015 JCT pvc high speed mixer
2015 JCT pvc high speed mixer
- 500 Set / Sets per Month
- Guangdong China (Mainland)
- T/T L/C Credit Card PayPal
Product Details
Condition: | New | Mixer Type: | Paddle | Product Type: | Paint |
Application: | Other, paint | Additional Capabilities: | Granulating | Place of Origin: | Guangdong, China |
Brand Name: | JCT | Model Number: | XJB Chocolate making machine | Max. Loading Capacity: | 1000L |
Voltage: | 380V | Power(W): | 2.2KW - 45KW | Dimension(L*W*H): | 1400*940*350~3800*3800*1800 |
Certification: | CE, ISO, SGS | Warranty: | 18 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
Standard Export Cases, Standard Neutral packing, wooden package
Product Description
Specifications
pvc high speed mixer
1. Use fo nail polish, dyes, sealant making.
2. SS304, SS316, Q235-B
3. High-speed and low-speed stirring
4. CE
2015 JCT pvc high speed mixer
Power Mixer Picture
1. INTRODUCTION OF POWER MIXER
Power Mixer is a high-efficient mixing and dispersion equipment. This machine is fully combined with the characteristics of Planetary mixer and Dispersion machine, integrating the advantages of both devices, ensure high-efficiency.
Power Mixer is applied for making Nail Polish, Dyes, Adhesives, Sealants, Pastes, Lithium Battery, etc.
2. TECHNICAL PARAMETERS OF POWER MIXER
Model | Volume (Liters) | Drive motor power (KW) | Blade speed (rpm) | Vacuum degree (Mpa) | Remark | ||
Mixing Motor | Dispersed motor | Low-speed rotation | High-speed disperser | ||||
DLH-5 | 5 | 1.1 | 1.1 | 0-110 | 0-1450 | -0.098 | Data in this table is just for reference, the actual data should be made according tospecific process requirements, material viscosity and othe demands. |
DLH-20 | 20 | 2.2 | 2.2 | 0-80 | 0-1450 | ||
DLH-50 | 50 | 4 | 3 | 0-80 | 0-1450 | ||
DLH-100 | 100 | 5.5 | 4-5.5 | 0-80 | 0-1450 | ||
DLH-200 | 200 | 7.5-11 | 7.5-11 | 0-80 | 0-1450 | ||
DLH-300 | 300 | 11-15 | 11-18.5 | 0-60 | 0-1450 | ||
DLH-500 | 500 | 18.5-22 | 18.5-30 | 0-60 | 0-1450 | ||
DLH-1000 | 1000 | 22-45 | 22-45 | 0-60 | 0-1450 | ||
DLH-1500 | 1500 | 30-55 | 30-55 | 0-60 | 0-1450 | ||
DLH-2000 | 2000 | 45-75 | 37-75 | 0-60 | 0-1450 | ||
DLH-3000 | 3000 | 75-110 | 75-110 | 0-60 | 0-1450 | ||
1. Lifting method: Hydraulic lift 2. Heating or cooling according to the actual requirement 3. Pressure range: -0.098~0.2mpa 4. Speed mode: Frequency control |
3. SUPERIORITY COMPARED WITH PLANETARY MIXER AND DISPERSION MACH
Mixing Effect of The Power Mixer
Mixing Blades of The Power Mixer
Structual Representation of The Power Mixer
4. PICTURES OF POWER MIXER
Power mxer & Hydraulic discharge machine
5.Packaging & Shipping
6.Our Services
7.Our customers
8.Company Information
1). About our company:
Our company is JCT Machinery Co., Ltd.
Specialized in this area since 2004, our company has over ten-year experience, and our CEO is a professional engineer who has 20 years' experience in what we are concerntrating on ! With time goes by, we have accumulated many pofessional and useful advanced techniques.
2). Powerful team:
A 5-experienced-engineer designing team + a 35-skilled-technician team + a 10- passionate-sales team make up the JCT big team. Our team has capable and professional abilities and very creative.
3). Our objective:
To satisfy our clients is our objective, everything we do is to meet our clients' requirements, to solve clients' difficulties, to help our clients to understand how to operate our equipments. We hope through the mutul effort, all of us can benefit a lot and develope together.
4). Achievement:
JCT was set up at 2004, through about 10 years' mutual effort, our products have been sold to most important industrict in China, such as Guangdong, Shangdong, Jiangsu, Zhejiang, Fujian and so on. And we have edged ourselves into the top 5 in China.
From 2009, JCT started the international marketing. Now, we have set our feet in North America, Europe, South Aria, Africa etc.
9.FAQ
Contact Us
Click here to learn more
our company wesite: http://gdjct.en.china.cn
pvc high speed mixer
Company Profile
Foshan JCT Machinery Co., Ltd. is a manufacturer of mixing machines, chemical mixers with well-equipped testing facilities and strong technical force.
With good quality, reasonable prices and stylish designs, our products are extensively used in resin, paint, white latex, hot melt adhesive, silicone sealant, PU sealant, liquid silica, silicone rubber, silicone oil, plasticine, chewing gums, chemical, food, cosmetic and other industries.
Our products are widely recognized and trusted by users and can meet continuously changing of economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
