vinyl coated gypsum ceiling tiles

Specifications

environmental,healthy, non-dust ,noxious-free, moisture-proof, sunken proof, and easy clean.

ATLANTIS superior PVC laminated gypsum ceiling board adopts ATLANTIS paper-faced gypsum board as the base board, and imported good quality latex painting, polythene compound pellicle, aluminum foil as the surface veneer material. Through a high technological manufacturing process. It has a character of safe, environmental,

healthy, non-dust ,noxious-free, moisture-proof, sunken proof, and easy clean.



It is a economical ,elegant, fashionable, ceiling decorative material. This superior material is mainly used in the indoor decoration of super class buildings such as hotels, restaurants, shopping malls theaters, danceries, cinemas, stations, auditoriums, offices, sitting rooms, business buildings, electronic workshops,precision apparatus rooms and industrial or residential buildings.



We have 5 series of products:

Painting relievo surface

Printing pellicle surface

Superior pellicle surface

Clean non-dust surface

Advanced pellicle +backside aluminum foil surface



Specifications:

1) Material:  paper-faced gypsum board

2) Thickness:7mm,7.5mm,8.0mm,8.5mm, 9mm,9.5mm,12mm,12.5mm

3) Sizes: 595 x 595mm, 600mmX600mm,595 x 1195mm, 603 x 603mm, 605mmX605mm,603mm x 1212mm,610mmX1220mm(2’X4’)

4) Size tolerance: length <±0.2mm, width < ±0.2mm, thickness <±0.5mm

5) Weight: 7mm=5.5kg/sqm,7.5mm=5.7kg/sqm,8.0mm=5.9kg/sqm,8.5mm=6.2kg/sqm,9mm=6.8kg/sqm,9.5mm=7.1kg/sqm,12mm=9.2kg/sqm,12.5mm=9.5kg/sqm

6) Strength: >160N

7) Characters: non-flammable B1, in accordance with Chinese standard GB8624-1997

8) Installation: match with ceiling T-bar



Packing:Export carton(8pcs or 10 pcs per carton with film)
