class SM slim hole sucker rod coupling
- 62500 Piece / Pieces per Month
- Tianjin Xingang
- T/T L/C D/P D/A
- API-7-1 Standard single cone drill bit
- API 16A cameron Annular BOP,Annual Blowout Preventer
- API 16A Cameron type Single / double Shear Ram BOP/Blowout Preventer for Oil Well Control
- Oilfield Butterfly Valve Pneumatic Vane Actuator Assembly Model 200 Coated
- Shaffer BOP elements and BOP spare parts,Pipe Ram, V Shear Ram, Casing Shear, Muti-Ram, Blind flang and so on
- API 16A oilfiled cameron BOP stack/ annular BOP/Ram bop manual
Product Details
Place of Origin: | Inner Mongolia, China | Brand Name: | LD | Model Number: | 5/8"-3/4" 3/4"-7/8" 7/8"-1" 1"-9/8" |
Type: | Other, sucker rod coupling | Machine Type: | Drilling Tool | Certification: | API |
Material: | Other, carbo or alloy steel | Processing Type: | Other, compressing | Use: | Well Drilling |
Product Description
Sucker Rod Coupling
Our Advantages:
1 API Certificate
2 R&D Ability
3 100% Inspection
4 0 Defect
5 Many years' exporting experience
Technical Parameters
Full Size Coupling
Size(in) | Coupling O.D W(mm) (+0.13,-0.25) | Length L(mm) (+1.57,-0.00) | Thread D.(in) | Length of Wrench Square (mm) | Hardness(HRA) |
5/8" | 38.10 | 101.6 | 15/16" | 31.8 | 56-62 |
3/4" | 41.28 | 1-1/16" | |||
7/8" | 46.00 | 1-3/16" | |||
1" | 55.60 | 1-3/8" | 38.1 | ||
1-1/8" | 60.33 | 114.3 | 1-9/16" |
Slim Hole Coupling
Size(in) | Coupling O.D W(mm) (+0.13,-0.25) | Length L(mm) (+1.57,-0.00) | Thread D.(in) | Length of Wrench Square (mm) | Hardness(HRA) |
5/8" | 31.75 | 101.6 | 15/16" | 31.8 | 56-62 |
3/4" | 38.10 | 1-1/16" | |||
7/8" | 41.30 | 1-3/16" | |||
1" | 50.80 | 1-3/8" | 38.1 |
Full Size Sub-coupling
Size(in) | Coupling O.D W(mm) (+0.13,-0.25) | Length L(mm) (+1.57,-0.00) | Small End Thread D. | Big End Thread D. | Hardness(HRA) |
5/8"-3/4" | 41.28 | 101.6 | 15/16" | 1-1/16" | 56-62 |
3/4"-7/8" | 46.00 | 1-1/16" | 1-3/16" | ||
7/8"-1" | 55.60 | 114.3 | 1-3/16" | 1-3/8" | |
1"-1-1/8" | 60.33 | 127.0 | 1-3/8" | 1-9/16" |
Slim Hole Sub-coupling
Size(in) | Coupling O.D W(mm) (+0.13,-0.25) | Length L(mm) (+1.57,-0.00) | Small End Thread D. | Big End Thread D. | Hardness(HRA) |
5/8"-3/4" | 38.10 | 101.6 | 15/16" | 1-1/16" | 56-62 |
3/4"-7/8" | 41.30 | 1-1/16" | 1-3/16" | ||
7/8"-1" | 50.80 | 114.3 | 1-3/16" | 1-3/8" |
Full Size Polished Connection
Size(in) | Coupling O.D W(mm) (+0.13,-0.25) | Length L(mm) (+1.57,-0.00) | Thread D.(in) | Vanish Cone | Hardness(HRA) |
5/8" | 38.10 | 101.6 | 15/16" | 9O | 56-62 |
3/4" | 41.28 | 1-1/16" | |||
7/8" | 46.00 | 1-3/16" | |||
1" | 55.60 | 1-3/8" | |||
1-1/8" | 60.33 | 114.3 | 1-9/16" |
Slim Hole Polished Connection
Size(in) | Coupling O.D W(mm) (+0.13,-0.25) | Length L(mm) (+1.57,-0.00) | Thread D.(in) | Vanish Cone | Hardness(HRA) |
5/8" | 31.75 | 101.6 | 15/16" | 9O | 56-62 |
3/4" | 38.10 | 1-1/16" | |||
7/8" | 41.30 | 1-3/16" | |||
1" | 50.80 | 1-3/8" |
Coupling Mechanical Properties
Tensile Strength Rm(Mpa) | Yield Strength Rel(Mpa) | Elongation Percentage A(%) | Reduction Percentage of Area Z(%) |
≥655 | ≥405 | ≥16 | ≥48 |
Manufacturing Workshop of coupling
sucker rod coupling
Sucker Rod Coupling Packaging
We are wiling to cooperate with customers from all the places and countries all over the world ,and it will be appreciated if you can provide us with precious suggestions. Looking forward to cooperating with you .
