Specifications
ANP Series Motor1. Gost standard
2. High efficiency
3. High starting torque
4. Energy saving
GOST MOTOR
ANP series three-phase electromotor, this motor has a very compact structure and attractive appearance. The sizes and mounting dimensions are produced according to the GOST standard. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance. They are mainly applied for machinery and equipment. Such as agriculture machinery, food machinery and air compressor.
We can also supply aluminum housing type for frame size below IEC160.
We can supply cast iron housing type for frame size from 56-355.
1) Frame sizes: 56--355
2) Rated power:0.12--315KW
3) Rated voltage: 220/380V;380/660V
4) Frequency: 50Hz,
5) Protection class:IP55
6) Insulation class: F
7) Materials: cast iron, aluminum (FRAME 63-132)
8) WFF:EFF2, EFF1
9) Poles: 2,4,6,8,10
10) Cooling method: IC411 (total-enclosed fan-cooled type)
11) Mounting types: IM1081 IM3081 IM2081
12) Operating mode: S1
13) Connection: "Y" type for 7.5kW and downwards, “D” type for 11kW
and upwards
14) Ambient temperature: -35oC < θ < 40oC
15) The altitude should be lower than 1,000m above the sea level
16) Relative humidity: not higher than 90%
17) Special motors can be designed according to customers' requirements
Packing:
1) Frame 63-100: carton boxes with foam
2) Frame 112-315: closed wooden boxes
GOST MOTOR
ANP series three-phase electromotor, this motor has a very compact structure and attractive appearance. The sizes and mounting dimensions are produced according to the GOST standard. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance. They are mainly applied for machinery and equipment. Such as agriculture machinery, food machinery and air compressor.
We can also supply aluminum housing type for frame size below IEC160.
We can supply cast iron housing type for frame size from 56-355.
1) Frame sizes: 56--355
2) Rated power:0.12--315KW
3) Rated voltage: 220/380V;380/660V
4) Frequency: 50Hz,
5) Protection class:IP55
6) Insulation class: F
7) Materials: cast iron, aluminum (FRAME 63-132)
8) WFF:EFF2, EFF1
9) Poles: 2,4,6,8,10
10) Cooling method: IC411 (total-enclosed fan-cooled type)
11) Mounting types: IM1081 IM3081 IM2081
12) Operating mode: S1
13) Connection: "Y" type for 7.5kW and downwards, “D” type for 11kW
and upwards
14) Ambient temperature: -35oC < θ < 40oC
15) The altitude should be lower than 1,000m above the sea level
16) Relative humidity: not higher than 90%
17) Special motors can be designed according to customers' requirements
Packing:
1) Frame 63-100: carton boxes with foam
2) Frame 112-315: closed wooden boxes
