CABLE STANDARDS
Up to 35mm2: generally to BS 7211
50mm2 and above: IEC 60502-1
APPLICATION
For installation where fire, smoke emission and toxic fumes
create a potential threat to life and equipment. Suitable for DC
power supplies on Telecom equipment and power applications
where flexibility is required. The cables produce no corrosive
gases when burnt which is important where electronic
equipment is installed.
CONSTRUCTION
Conductor
Class 5 flexible annealed copper conductor according to
BS EN 60228 (previously BS 6360)
Insulation
XLPE (Cross-Linked Polyethylene)
Sheath
LSZH (Low Smoke Zero Halogen)
CHARACTERISTICS
Voltage Rating (Uo/U)
Up to 35mm2: 450/750V
50mm2 and above: 600/1000V
Temperature Rating
Fixed: 0°C to +90°C
Minimum Bending Radius
Up to 50mm2: 3 x overall diameter
70mm2 and above: 4 x overall diameter
Sheath Colour (Insulation Colour)
Blue (Blue) Grey (Grey) Green/Yellow (Green/Yellow)
Special colours to order
