Three phase multifunction energy meter
As a professional manufacturer, YTL designs and produces electronic energy meters which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications
YTL is devoted to develop and design all types of electronic energy meters, concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.
1.Product Details | ||
Product Name | Three phase multifunction Energy meter | |
Installation type | Suspension type | |
Module No. | D526002( multifunction Energy meter ) | |
Brand | YTL ( multifunction Energy meter ) | |
Rated Current | 1.5(6)A;5(30)A;10(40)A;20(80)A;5(100)A | |
Reference Voltage | 3*110V; 3*220V/380V; 3*230/400V | |
Frequence | 50/60Hz | |
Display Mode | LCD | |
Accuracy | 1.0 | |
Impulse Constant | 1000imp/kWh | |
Start Current | 0.004Ib | |
Connection Mode | Direct mode | |
Communication& Protocol | / | |
PowerConsumption | ≤1.0W;≤0.3VA | |
Material of meter case | PC | |
Size | 170mm*72mm*230mm | |
Certificate | CE | |
Standard | IEC62052-11/IEC62053-21 | |
2.Functions and characteristic | ||
A. With simple structure and high reliability, the meter adopts three-chip synthetic technology and some certain constants can be decided by users. | ||
B. Measure and calculate the accumulative active power with power indicator and energy indicator | ||
C. With wide measuring range without hooks, shunt sampling is adopted to avoid tampering by pulling off the hooks or shunting direct current | ||
… | ||
3.Outer and mount dimension: | ||
| ||
4.Wiring diagram: | ||
| ||
5.TransactionInformation | ||
MOQ | 500pcs | |
Sea Port | Shanghai | |
Payment Terms | TT prepayment | |
Supply Ability | 500,000pcs of energy meter per month | |
Delivery time | 20-25 days | |
Normal Package | white box or colorful box for energy meter | |
If you are interested in our three phase multifunction energy meter, pls feel free to contact us at any time.
