Home > Computer Products > Storage Device > USB Flash Disk > Reliable Commnucation Interface for Energy Meter

Reliable Commnucation Interface for Energy Meter

Name: Reliable Commnucation Interface for Energy Meter
Brand: YTL(energy meter)
SKU: 118726425

Reliable Commnucation Interface for Energy Meter thumbnail-1

Reliable Commnucation Interface for Energy Meter photo-1

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Products Status:

Stock

Capacity:

Other

Material:

Plastic

Contact Supplier Request Quote Chat Now

Zhejiang Yongtailong Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Products Status Stock

Capacity Other

Material Plastic

Encryption No

Brand Name YTL(energy meter)

Model Number DDS-1Y

Place of Origin Zhejiang, China

Specifications

commnucation interface for energy meterThis device could
transmit meter data into your PC.
Used for far-infared,reliable

We design and produce far infrared USB . It can be connected to the PC directly.

Specification and main technical parameter:

1. Length of the signal radiated 940nm;

2. Reference Temperature:23±2.

3. The emitter is ON≥2500uW/cm²3. The emitter is OFF≤10uW/cm²; the emitter on ray axis is far away from emitter surface 1m which will arise IR signal radiated Ee/r≥50mW/m2

4.Modulate IR port of ray radiation DBC caseθ≥15°

5. Modulate IdentityCarrier wave frequency 38kHz±1kHz

6. Supporting baud RateThe biggest transfers rate no less then2400bps

USB interface

The USB far infrared use the standard USB interface. It can be connected to the PC directly. The supply power is from the USB interface.

Please install the USB driver when it is used for the first time. The driver is in the device disk.

After installed the USB driver, please add a serial port. The user can connect the optical head to the PC with this port. And then communicate with the other device which has the function of optical communication.
