Duct Machine---auto Duct Line 5
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Pipe Production Line
Pipe Material:
Other, Galvanized steel
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Pipe Production Line
Pipe Material
Other, Galvanized steel
Application
Other, HVAC industry
Production Capacity
15m/min
Place of Origin
Tianjin, China
Brand Name
COORIG
Model Number
ADL-5-1500
Voltage
380V/3PH/50Hz
Power(W)
36 KW
Dimension(L*W*H)
22500*4000*1500
Weight
11000 Kgs
Certification
ISO 9001
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Auto Duct Line 5
This line mainly being used to complete the TDF flange ducts, the production capacity is 800 to 2000 square meters per day. After input the dimensions of the TDF flange duct you want to process and then the machine can complete the following functions: Uncoil, leveling, beading, notching and punching, shearing, Pittsburgh locking, TDF flange forming and hydraulic folding.
Basic Configuration:
- A material frame(2 coils; the max loading per coil is 7 tons)
- A transmission frame
- A main machine
- A CNC system
- A moveble high-speed Pittsburgh lock forming machine
- A duplex TDF flange forming machine
Product features:
- A motor driven speed adjustable decoiler (Optional 8 or 10 tons of hydraulic decoiler)
- The material frame being controlled by the independent speed adjustable converter motor
- with the material processing saving mode ,users can reduce the waste of sheet metal significantly to less than 20mm per material coiler.
- the input adopted two models:screen touch and keyboard which ensures stability of the system.
- A servo motor driven material feeding and folding platform
- The speed of each part can be adjusted as needed
- With production management function for day count and total count
- Support production data records export and print function (optional)
Main Technical Data
| No. | Model |
Capacity in mild-steel thickness range (mm) |
Max-width(standard) (mm) |
Max-working speed (m/min) |
Coiler max-weight (Kg) |
L*W*H (mm) |
Power (Kw) |
Weight (Kg) |
| 1005-3 | ADL-5-1250 | 0.5-1.2 | 1250 | 15 | 7000 | 22500*4000*1500 | 33 | 10000 |
| 1005-4 | ADL-5-1500 | 0.5-1.2 | 1500 | 15 | 7000 | 22500*4000*1500 | 36 | 11000 |
Appearance of the machine:
Certificate:
