Digital Led 400W 10A DC Step-up Constant Voltage Current Boost Converter 8V-80V dc to dc Boost Converter
Negotiable
MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
U020V
Type:
Voltage Regulator
Brand Name:
Geree
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
150W Boost DC-DC 8-32V to 9-46V Converter ModuleNegotiableMOQ: 20 Pieces -
Factory Wholesale DC-DC Step-up Converter 12V to 15V/19V/24V DC DC Boost Converter Module for Car Laptop Computer GoodNegotiableMOQ: 20 Pieces
-
10A DC To Dc Buck Boost ConverterNegotiableMOQ: 20 Pieces
-
Favorites Compare DC DC Step up Boost Converter IN 6V-40V to OUT 8V-80V Adjustable Constant Current 0-9.99A 400W With LED VoltaNegotiableMOQ: 20 Pieces
-
Boost DC/DC Converter Design 400W 10A 8V-80V dc to dc Boost ConverterNegotiableMOQ: 20 Pieces
Model Number
U020V
Type
Voltage Regulator
Brand Name
Geree
Place of Origin
Guangdong, China
-
- Description:
-
Features:
module:Digital-controlled constant voltage constant current Step-up module
4 bit high brightness LED, real-time display output voltage, current , you can manually switch shown , can also be set auto rotate
input voltage:DC 6v-40v
Input current :15A MAX
output voltage:8-80v
output current:0-9.99A
Voltage/current resolution:0.01V 0.01A
output power:400w max
effective power:P=input voltage x 10A
Conversion efficiency: up to 95%(input voltage, current; output voltage and current impact of conversion efficiency )
short-circuit protection:15A fuse
Size :86*75*63mm
weight:295g
Applications:
1.DIY an output adjustable power supply, only need to enter the access 6v,12V.24v .36v power supply or battery can be (14V-80V) free continuous adjustment, but the output voltage can not be lower than the input voltage.
2 universal car laptop power supply. Input connected to 12V power supply, the output voltage can be adjusted to the notebook need work.
3.Boost charger with 12V power supply is higher than 12V battery charging, for example, 24V battery and charging current can be adjusted.
4.For electronic equipment power supply, as long as the voltage regulator to the required voltage and current does not exceed the rated current is normal
Package Contents
100% Brand New
1pcs Digital Led 400W 10A DC Step-up constant voltage current boost Converter 8V-80V
