Specifications

1) DC DC Converter step down Module
2) Input voltage: 5V-60V
3) Output parameter: 1.25V-26V





DC-DC LM2596HV Buck Converter 5V-60V to 1.25V-26V Power Module 48V to 3V/5V/12V

OR

LM2596HV DC to DC Buck Converter 5V-60V to 1.25V-26V 20W Power Module 24V to 12V



Description

Specifications:

• Input voltage range: 5V-60V (Maximum within 55V continuously)
• Output voltage range: 1.25V-26V( Continuous adjustable)
• Maximum output current: 3A
• Continuously working current: 1.5A( Output total power within 20W)
• Size: (L)50*(W)25*(H)14mm

Connection :

• IN + input positive, IN – output negative
• OUT + output positive,OUT – output negative

Package included:

• 1 x LM2596HV DC-DC Buck Converter
