Specifications
1)Buck Step-Down Adjustable Power Supply Board2)Input voltage: 16-40V
3)Output voltage: 1.0-12V 6A
DC Power Converter Input: 16-40V, Output: 1.0-12V 6A
Buck Step-Down Adjustable Power Supply Board
Feature:
Synchronous rectification DC Buck Converter
Dimensions: length (68mm) wide (43mm) high (22mm)
Output voltage :1.0-12V
Output current: 6A (natural cooling)
No-load current: 10.2mA (24V to 12V) 7.7mA (24V to 5V)
Load starting current Rated 6A, 7A.
Type of protection: Undervoltage shutdown, overcurrent shutdown
Please try to avoid Frequently short-circuit when Normal output. Minimize the impact on burn mos tube.
Technical Overview:
Use Synchronous rectifier controller and 3.7 milliohms low impedance NMOS switch, Can be reliably continuous work in the 6A output current.
Light load Maximum efficiency More than 98%!
Note:
When your need large current output, Please use the two-terminal wiring, Best is Direct welding, To avoid terminal Impedance is too large to make output voltage drop.
