MAX7219 Dot Matrix Module MCU Control Display Module

MAX7219 Dot Matrix Module MCU Control Display Module thumbnail-1
MAX7219 Dot Matrix Module MCU Control Display Module thumbnail-2
MAX7219 Dot Matrix Module MCU Control Display Module photo-1
MAX7219 Dot Matrix Module MCU Control Display Module photo-2
Negotiable MOQ: 20 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
D/C:
Wiring instructions: 1.The module left as an input port to the output port on the right. 2.The control of a single module, simply input port to the CPU 3.Multiple modules cascade input termination CPU, 2 output termination module, a module of the input of the input terminal, the output terminal of the first two modules of the first three modules, and so on ...
Model Number:
F068M
Type:
Other, module
Contact Supplier Request Quote Chat Now
Shenzhen Geree Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen/HongKong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
D/C Wiring instructions: 1.The module left as an input port to the output port on the right. 2.The control of a single module, simply input port to the CPU 3.Multiple modules cascade input termination CPU, 2 output termination module, a module of the input of the input terminal, the output terminal of the first two modules of the first three modules, and so on ...
Model Number F068M
Type Other, module
Brand Name Geree
Place of Origin Guangdong, China




MAX7219 Dot matrix module MCU control Display module



MAX7219 Dot matrix module MCU control Display moduleMAX7219 Dot matrix module MCU control Display moduleMAX7219 Dot matrix module MCU control Display module
Module parameters:



1.A single module can drive an 8 * 8 common cathode lattice
2.Module Operating voltage: 5V.
3.Module size: 3.2 cm long X 3.2 cm wide X 1.5 cm high
4.With four screws hole, aperture 3mm, by using our M3 Tongzhu fixed
5.Module with input and output interfaces, supports multiple modules cascade



Wiring instructions:
1.The module left as an input port to the output port on the right.
2.The control of a single module, simply input port to the CPU
3.Multiple modules cascade input termination CPU, 2 output termination module, a module of the input of the input terminal, the output terminal of the first two modules of the first three modules, and so on ...



51 MCU, for example:
VCC → 5V
GND → GND
DIN → P22
CS → P21
CLK → P20



Package:
1x MAX7219 Dot matrix module



Send Inquiry to This Supplier
