Hot Selling High Efficiency European Standard Water to Water Heat Pump

Hot Selling High Efficiency European Standard Water to Water Heat Pump thumbnail-1
Hot Selling High Efficiency European Standard Water to Water Heat Pump photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
HICOOL
Model Number:
H-WP36B
Contact Supplier Request Quote Chat Now
Huizhou Hicool Climate Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name HICOOL
Model Number H-WP36B
Type Other, commercial air conditioner
Application Other
Certification CE

Specifications

Water cooled (heat pump) packaged unit
Die formed plate type aluminium fins mechanically bonded to high efficiency inner groove

                                     Water cooled (heat pump) packaged unit

outline

Water Cooled Packaged units are new models developed by Hicool, characterized in high-efficiency and non-pollution. Cooling and heating can be selected by purpose that reduces running cost. It combined the merits of both central air conditioners and home air conditioners, so the air conditioning room temperature can be adjusted separated or centralized.
feature

Air Coil
Die formed plate type aluminium fins mechanically bonded to high efficiency inner grooved copper tubes.



Fans
Forward curved double inlet fans in involute scrolls and fitted directly to a resiliently mounted motor. Speed tappings allow airflow selection to match external duct pressure.





Parameter





 Model H-WP30B H-WP36B H-WP42B H-WP60B H-WP75B H-WP95B H-WP125B
Cooling Capacity kW 3.0 3.6 4.1 6.1 7.8 9.2 13.0
Heating Capacity kW 3.1 3.7 4.2 6.3 8.0 9.3 13.3
Rated Input Power  Cooling kW 0.8 1.0 1.1 1.7 2.0 2.7 3.6
 Heating kW 0.9 1.1 1.2 1.8 2.1 2.8 3.7
Rated Input Current  Cooling A 3.6 4.6 5.1 8.1 9.6 11.5 6.1
 Heating A 3.9 5.0 5.5 8.6 10.0 11.7 6.3
 Power Supply  220V~/50Hz/1Ph 380V~/50Hz/3Ph

Compressor 		 Type  Rotary
Scroll
 Quantity 1 1 1 1 1 1 1
 Refrigerant R22(R410A)
Refrigerant Charge kg 1.2 1.4 1.6 2.0 2.2 2.7 3.0
Protection High/low pressure protection, over-heat protection, over-current protection, water break protection
Air Flow Volume m3/h 550 600 850 1300 1600 1800 2400
Fan Power W 25 30 40 50 70 90 120
Static Pressure Pa 30 30 30 30 30 30 40
Cooling Water Flow m3/h 0.60 0.75 0.80 1.20 1.80 2.15 2.67

Cooling Water Connecting Pipe 		DN20 DN20 DN20 DN25 DN25 DN32 DN32
Water Resistance kPa 6.0 8.0 10.0 12.0 14.0 23.0 25.0
Noise dB(A) 38 39 41 43 45 47 48
Net Dimension(LxWxH) mm 1060×580×410 1060×580×410 1060×580×410 1144×645×480 1144×645×480 1144×645×480 1350×645×550
 Net Weight  kg 58 65 72 76 80 95 105
Packing Dimension(LxWxH) mm 1180×600×480 1180×600×480 1180×600×480 1260×665×550 1260×665×550 1260×665×550 1480×665×620
 Gross Weight  kg 62 69 76 80 85 100 110
Note:
1) Nominal cooling conditions: indoor dry bulb: 27°C, indoor wet bulb: 19°C, cooling water inlet: 30°C, cooling water outlet: 35°C
2) Nominal heating conditions: indoor dry bulb: 20°C, indoor wet bulb: 15°C, cooling water inlet: 20°C, cooling water outlet: 15°C.
3) Applicable temperature range: 21-30°C
4) Manufacturer keeps the right to change the above parameter without prior notice





Sample show





Hot Selling High Efficiency European Standard Water to Water Heat PumpHot Selling High Efficiency European Standard Water to Water Heat Pump
