Specifications
Safely and reliable,high energy efficiency ratio,
energy-saving,
widely used.
Carrier Heat Pump
1. Based on inverse cannot cycle principle, the unit can transfer energy in air into water through heat pump system, raise the water temperature to meet service conditions by consuming part of electric power.
2. It has high energy efficiency ratio, can produce 4kw heat by consuming every 1kw electric power. Comparing with traditional electric water heater which produces 0.95kw heat by consuming every 1kw electric power, its economic benefit is more than 4 times bigger than traditional heaters, or more than 2 times bigger than coal/oil (natural gas) furnace. Comparing with solar water heater, it is not restricted by installation conditions or weather conditions, can be used in all seasons.
3. Safely and reliable, electricity will not contact water directly during heating process, users will not suffer electric shock risk, nor explosion risk or poisoning risk of oil/gas furnace.
4. Environmental friendly, it will consume only part of electric power during operation, will not bring any pollution to the environment.
Application range:
It is mainly applied to houses, hotels, restaurants, schools, hospitals, swimming pools, bathhouses, large high grade office buildings which have requirements on hot water.
Parameter
| Model | DKFXRS-4Ⅰ/P | DKFXRS-6Ⅰ/P | DKFXRS-10Ⅰ/P | DKFXRS-16Ⅰ/P | DKFXRS-20Ⅰ/P | ||
| Heating Capacity | kW | 4 | 6 | 10.5 | 15.8 | 20.6 | |
| Rated Input Power | Heating | kW | 1.25 | 1.85 | 2.65 | 3.92 | 5.3 |
| Rated Input Current | Heating | A | 6.25 | 9.25 | 12 | 17.8 | 24.1 |
| Rated Water Output | L/h | 80 | 120 | 220 | 340 | 440 | |
| Top Out Water Temperature | 60°C | ||||||
| Power Supply | 220V/50Hz 1P | 380V/50Hz/3P | |||||
| Compressor Quantity | Sets | 1 | 1 | 1 | 1 | 1 | |
| Fan Quantity | Sets | 1 | 1 | 1 | 1 | 1 | |
| Refrigerant | R22(R410A) | ||||||
| Refrigerant Charge | kg | 0.8 | 1.8 | 2 | 3.8 | 4.5 | |
| Ambient Temperature | -8°C~43°C | ||||||
| Control Manner | Central control and network control | ||||||
| Protection | High/low pressure protection, over-heat protection, over-current protection, water-break protection | ||||||
| Noise | dB(A) | 50 | 52 | 57 | 59 | 60 | |
| Pump | Type | Stainless Multi-stage | |||||
| Pump Head | m | 5 | 5 | 10 | 13 | 13 | |
| Flow | m3/h | 0.68 | 1.1 | 1.8 | 2.7 | 3.5 | |
| Power | kW | 0.055 | 0.055 | 0.25 | 0.37 | 0.37 | |
| Quantity | Sets | 1 | 1 | 1 | 1 | 1 | |
| Water Gap Spec | Nut | inches | 3/4" | 3/4" | 1" | 1" | 1-1/4" |
| Net Dimension(LxWxH) | mm | 880×360×630 | 880×360×630 | 1020×375×845 | 1000×555×1420 | 1000×555×1420 | |
| Net Weight | kg | 58 | 65 | 80 | 180 | 220 | |
| Packing Dimension(LxWxH) | mm | 930×410×760 | 930×410×760 | 1060×450×1000 | 1090×650×1590 | 1090×650×1590 | |
| Gross Weight | kg | 65 | 72 | 92 | 200 | 240 | |
| Note:1) Nominal heating capacity is determined when ambient temperature is 20°C. 2) Hot-water feeding: temperature of compensating water is 15°C, outflow is 55°C. | |||||||
Sample Show
