175 Kva Diesel Generator
US$ 8,600 - 11,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YLFDJ
Model Number:
YLGF-140
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Foshan 5kw Portable Diesel Generator Silent Type Quality ChoiceUS$ 700 - 900MOQ: 1 Set -
Good Quality 6.5KVA Diesel Aircooled Silent Generator With ATS,copper Alternator. Quality ChoiceUS$ 650 - 760MOQ: 1 Set
-
10kva Single Phase or Three Phase Reasonable Price Chinese Silent Diesel Generator SetUS$ 1,966 - 2,300MOQ: 1 Set
-
10kva Diesel Generator With ATS.Full Copper Alternator Quality ChoiceUS$ 1,966 - 2,300MOQ: 1 Set
-
10 Kva Generator PriceUS$ 1,966 - 2,300MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
YLFDJ
Model Number
YLGF-140
Output Type
AC Three Phase
Speed
1500RPM/1800RPM
Frequency
50HZ/60HZ
Rated Power
140KW
Rated Voltage
230V/400V/110V
Rated Current
252A
| Genset Model | YLGF-140 | |||||
| Genset | Power Capacity (kw/kva) | 140/175 | ||||
| Rated Voltage (V) | 400/230 | |||||
| Rated Current (A) | 252 | |||||
| Rated Frequency (Hz) | 50/60 | |||||
| Rated Speed (rpm) | 1500/1800 | |||||
| Power Factor / Phase | Cos 0.8 Lagging, 3 phase | |||||
| Cooling System | Closed cycle water-cooled with fan,water tank | |||||
| Overall Dimension (L×W×H) (mm) | 1455*762*1156 | |||||
| Gross Weight (kg) | 2500 | |||||
| Engine Brand | Shangchai | |||||
|
Diesel Engine |
Engine Model | SC8D220D2 | ||||
| Prime Power (kw) | 140KW | |||||
| Engine Structure | 6 Cylinder,Vertical,Inline,4 stroke | |||||
| Bore×Stroke (mm) | 114*135 | |||||
| Displacement (L) | 8.28 | |||||
| Compression Ratio | 17:1 | |||||
| Lube Capacity (L) | 22 | |||||
| Fuel System | PT type fuel injection pump | |||||
| Fuel Consumption (g/kw.h) | 200 | |||||
| Lube Consumption (g/kw.h) | 0.5% | |||||
| Rotating Speed (rpm) | 1500/1800 | |||||
| Speed Governing | electronic speed governor | |||||
| Starting Method | By 24V batteries | |||||
| Alternator Brand | YLFDJ | |||||
| Alternator | Alternator Model | YLW-140 | ||||
| Insulation Class | Class H | |||||
| Steady Voltage Regulation | ≤ +/- 0.5% | |||||
| Instant Voltage Ragulation | -15%~+20% | |||||
| Voltage Fluctuation Rate | ≤ +/- 0.5% | |||||
| Steady Frequency Regulation | ≤ +/- 0.5% | |||||
| Instant Frequency Ragulation | -7%~+10% | |||||
| Phase/Connection Type | 3 phase 4 wire/Y type | |||||
| Controller | Controller Brand | ZZ6110 | ||||
Payment & Delivery Terms
1.Minimum Order Quantity: 1 set.
2.Packing Details: standard export packing.
3.Delivery Time: 30 working days after receipt of deposit or original L/C.
4.Payment Terms: T/T (30% as deposit,the balance to be paid before delivery) or L/C.
5.Valid time of the quotation: 30 days.
Attachment list
1.Fuel connecting pipes
2.12V DC battery c/w battery cables 2 sets
3.Industrial type silencer c/w stainless steel flexible exhaust bellows
4.Shock absorption rubbers 4 pcs
5.The tool kit and 1 set of manuals (English version).
