High Power Silent Diesel Generator 750KVA(600KW) With Perkins Engine (2806A-E18TAG2)
US$ 99,976 - 113,472
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YLFDJ
Model Number:
2806A-E18TAG2
Payment & Shipping
Payment Methods:
Port of Shipment:
GUANGZHOU SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Global Guaranteed 250KVA (200kw) Silent Diesel Generator Set With Perkins Engine.US$ 27,932 - 31,727MOQ: 1 Set -
Economical Efficiency 500KVA (400kw) Silent Diesel Generator Set With Perkins Engine(2506A-E15TAG2)US$ 48,749 - 55,286MOQ: 1 Set
-
Silient Type 400KVA (320kw) Diesel Generator Set With Perkins Engine.US$ 40,858 - 46,212MOQ: 1 Set
-
Convenient Use Silent 150KVA (120KW) Diesel Generator Set 78db With Perkins Engine(1006-6TAG2).US$ 15,175 - 17,187MOQ: 1 Set
-
High Power Diesel Generator 750KVA(600KW) With Perkins Engine (2806A-E18TAG2)US$ 89,976 - 103,472MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
YLFDJ
Model Number
2806A-E18TAG2
Output Type
AC Three Phase
Speed
1500rpm/1800rpm
Frequency
50hz/60hz
Rated Power
600kw/750kva
Rated Voltage
400/230V/110V
Rated Current
1080
| Genset Model | YLGF-600 | |||||
| Genset | Power Capacity (kw/kva) | 600/750 | ||||
| Rated Voltage (V) | 400/230/110 | |||||
| Rated Current (A) | 1080 | |||||
| Rated Frequency (Hz) | 50/60 | |||||
| Rated Speed (rpm) | 1500/1800 | |||||
| Power Factor / Phase | Cos 0.8 Lagging, 3 phase | |||||
| Cooling System | Closed cycle water-cooled with fan,water tank | |||||
| Overall Dimension (L×W×H) (mm) | 4500x1750*2300 | |||||
| Gross Weight (kg) | 5500 | |||||
| Engine Brand | Perkins | |||||
|
Diesel Engine |
Engine Model | 4006-23TAG2A | ||||
| Prime Power (kw) | 600/750 | |||||
| Engine Structure | 6Cylinder,Vertical,Inline,4 stroke | |||||
| Bore×Stroke (mm) | 105x127 | |||||
| Displacement (L) | 3.3 | |||||
| Compression Ratio | 17.25:1 | |||||
| Lube Capacity (L) | 7.9 | |||||
| Fuel System | PT type fuel injection pump | |||||
| Fuel Consumption (g/kw.h) | 209 | |||||
| Lube Consumption (g/kw.h) | 2 | |||||
| Rotating Speed (rpm) | 1500/1800 | |||||
| Speed Governing | electric speed governor | |||||
| Starting Method | By 12V batteries | |||||
| Alternator Brand | YLFDJ | |||||
| Alternator | Alternator Model | YLW-600 | ||||
| Insulation Class | Class H | |||||
| Steady Voltage Regulation | ≤ +/- 0.5% | |||||
| Instant Voltage Ragulation | -15%~+20% | |||||
| Voltage Fluctuation Rate | ≤ +/- 0.5% | |||||
| Steady Frequency Regulation | ≤ +/- 0.5% | |||||
| Instant Frequency Ragulation | -7%~+10% | |||||
| Phase/Connection Type | 3 phase 4 wire/Y type | |||||
| Controller | Controller Brand | ZZ6110 | ||||
Payment & Delivery Terms
1.Minimum Order Quantity: 1 set.
2.Packing Details: standard export packing.
3.Delivery Time: 30 working days after receipt of deposit or original L/C.
4.Payment Terms: T/T (30% as deposit,the balance to be paid before delivery) or L/C.
5.Valid time of the quotation: 30 days.
Attachment list
1.Fuel connecting pipes
2.12V DC battery c/w battery cables 2 sets
3.Industrial type silencer c/w stainless steel flexible exhaust bellows
4.Shock absorption rubbers 4 pcs
5.The tool kit and 1 set of manuals (English version).
