Standalone Control Access Door Opener

Name: Standalone Control Access Door Opener
Brand: Crypton
SKU: 118608161

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Crypton

Model Number:

SA-200

Shenzhen Crypton Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

HK/Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Crypton

Model Number SA-200

standalone control access door opener

SA-200 Non-waterproof Metal Access Control

Feature:

1	Strong Zinc Alloy Electroplated anti-vandal case
2	Indoor use
3	Full programming from the keypad
4	2000 uses, supports Card, PIN, Card + PIN
5	Can be used as a stand alone keypad
6	Backlight keys
7	Wiegand 26 output for connection to a controller
8	Adjustable Door Output time, Alarm time, Door Open time
9	Very low power consumption (30mA)
10	Fast operating speed, <20ms with 2000 users
11	Lock output current short circuit protection
12	Easy to install and program
13	Built in light dependent resistor (LDR) for anti tamper
14	Built in buzzer
15	Red, Yellow and Green LEDS display the working status

Specification:

Operating Voltage	9-28V DC/AC
User Capacity	2000
Card Reading Distance	3-6 cm
Active Current	<60mA
Idle Current	25±5 mA
Lock Output Load	Max 3A
Alarm Output Load	Max 20A
Operating Temperature	-45~60°C
Operating Humidity	10%- 90% RH
Adjustable Door Relay time	0 -99 seconds
Adjustable Alarm Time	0- 3 minutes
Wiegand Interface	Wiegand 26 bit
Wiring Connections	Electric Lock, Exit Button,, External Alarm
Dimensions	L120 x W80x H25 mm
