Access Control Kits for CF1200 Finger Print Access Control
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Crypton
Model Number:
CF1200 Finger Print
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong or Shenzhen for Access Control Kits for CF1200 Finger Print Access Control
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Access Control Kit for Finger Print Password Keypad DoorNegotiableMOQ: 1 Piece -
Access Control SetNegotiableMOQ: 1 Piece
-
Swipe Card Machines and CardsNegotiableMOQ: 1 Piece
-
Controller With Metal Casing From Crypton Azura TanNegotiableMOQ: 1 Piece
-
Magnetic Card Door Security SystemNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Crypton
Model Number
CF1200 Finger Print
| Access Control Kits for CF1200 Finger Print Access Control | |
|
Base on the price,you will get: 1 X CF1200 Finger Print Access Control 1 X PS-300B Power Supply 5A 1 X EB-18 Plastic Exit Button 1 X EL-600ST 280KG Magnetic Lock with LED and door detection 1 X LZ Bracket 5 X EM-22 RFID Thin Cards | |
| Parameter for CF1200 Finger Print Access Control | |
| Hardware platform | ARM9 |
| Fingerprint collector | Fingerprint sensing optical Blu ray fingerprint collector |
| Screen | 1.8inch TFT-LCD widescreen HD color LCD |
| Fingerprint Capacity | 1000(standard),Can be extended to 3000,5000 |
| Record Capacity | 100000 |
| Communication Modes | USB. RS485. TCP/IP |
| U disk Function | Support upload and download |
| ReadCard module | The standard 125K HZ RFID and optional 13.56MHZ Mifare |
| Name Display | Display |
| Fingerprint Image Display | Display |
| Wiegand | In&out |
| Recognition Speed | <1 second |
| LED | Red & Blue |
| Alert Tone | Buzzer |
| Alarm Function | Anti-dismantle.Force to open door. Open door overtime |
| Language Choice |
English,Japanese,Korean,Thai,Indonesian, TiengViet,Spanish,French,Portuguese,German, |
| Temperature of use | -25 ~ 45 |
| Work humidity | 20% ~ 80% |
| Power supply | +12V |
| Size | 185mm X 60mm X 30mm |
| | |
| Specification for PS-300B Power Supply 5A | |
| AC Input Voltage | AC 220V 50Hz |
| Output Voltage | DC12V |
| Output Electric Current | 5A |
| Output Power | 60W |
| Operating Temperature | -20"C-+60'C |
| Operating Humidity | 0.9 |
| ACB-PS08A size | 374 X 262 X 67 mm |
| | |
| Specification for EB-18 Plastic Exit Button | |
| Dimensions | 86Lx86Wx20H(mm) |
| Standard Structure | Fireproof Material |
| Current Rating | 3A,36VDC Max |
| Output Contact | NCCOM |
| Mechanical Life | 1000000 tested |
| Suitable for Door | Hollow Door |
| Operating temp | 10~+55°C(14-131F) |
| Panel Material | Fireproof Material |
| Weight | 0.15kg |
| | |
| Specification for EB-600ST 280KG Magnetic Lock | |
| lock size | 250Lx42Wx25H(mm) |
| plate | 180Lx38Wx11H(mm) |
| Finishes for Shell | Anodized aluminum surface texture processing |
| Finishes for Magnetic | Zinc |
| Finishes for Armature | Zinc |
| Holding Force | 280kg (600Lbs) |
| Voltage | DC12V or DC24V (adjustable) |
| Current Draw | 12V/500mA 24V/250mA |
| Signal Output | Dry Contact, Max Rating of Contact Current 3A |
| Surface Temp | ≤+20°C |
| Operating Temp | below 55 to above 55 (14-131F) |
| Suitable Humidity | 0~90%(non-condensing) |
| Weight | 2kg |
| | |
| Specification for LZ-600 LZ Bracket for Magnet Lock | |
|
LZ Bracket is for Inward Door 1: Material Selection: High Strength Aluminum, Sandblast Finished 2: Suitable for Door: In-swing Door 3: Opening Mode: 90° Degress Door 4: Finished for Shell: Anodized aluninum | |
| | |
| Contact us - Ms Azura TAN | |
| | |
...
