LTG8000 20KW portable x-ray machine cost manufacturer

Key Features

The HF-ray machine controlled by microprocessor is compact and integrated highly.

The advanced design of  two keys operation just needs to set the value of kV and mAs.

Other parameters can be set automatically.

The specific X-ray table adopts integrated design and inner balance mechanism with attracting profile

It is easy to install and operate with innovative structures.

Components

Intelligent operation console,high frequency (HF)and high voltage(HV)X-ray generator,X-ray

tubea assembly,integrated X-ray table,electric  controller and X-ray chest stand(optional).

Applications

It can be widely used in various levels of  hospital to make general radiophy or ray-filter radiographyof

abdomen,limbs,skeleton,head,chest and other parts in supine position,lateral position and

Parameters of Main Unit

Voltage:380±10%,frequency 50Hz±2%;

HV frequency at conversion:50KHz;

The maximum output of power:20kW;

The maximum tube voltage:125kV;

The maximum tube current:200mA(current range:80~200mA)

The maximum mAs:320mA;

X-ray tube:small focus1.0mm/big focus2.0mm.

Parameters of X-ray Table

The height of table top to ground:690mm;

Horizontal movement distance of table top:220mm;

Vertical movement distance of table top:900mm;

Vertical movement distance of filter:540mm;

Suitable for the loading of various X-ray cassettes;

Focus-Film distance of X-ray tube assembly:60~1210mm

The rotation range of X-ray tube assembly around the center of pillar:3 steps;

The rotation range of X-ray tube assembly around the center of horizontal arm:±90;

The vertical movement along ground rail of X-ray tube assembly:1320mm;

Beam limiter is equipped with point light  and 30s delay mechanism;

Ray-filter grid:grid ratio 10:1,grid density≥40 lines/cm.
