LTE3 Portable Doppler Color Ultrasound Scanner

General Information

Dimensions and Weight ..

.Dimensions of main unit (approx.):

     1020mm  (Length)*630mm  (Width)*1365mm  (Height)

 .Net weight of main unit (approx):    125kg (no probe included)

Electrical Power

Power supply voltage: Auto adaptable for AC230V+10% and AC110V+10%

  .Power supply frequency: 50/60 Hz

 .Power consumption: 600 VA

    User   Interface..

Operation Panel

 .Control panel

 .Alphanumeric keyboard

.8 TGC Slides

 .Interactive backlit keys

Display Screen

  .High resolution color LCD

     -  Diagonal dimension: 19 inch

     -  Resolution: 1280X1024

     -  Brightness adjustment

 .Integrated speaker

     -   Volume adjustable

       System  Overview

Applications

.Abdomen

 .Gynecology

.Obstetrics

 .Urology

.Small Part

 .Pediatrics

 .Vascular

 .Musculoskeletal

Scanning Method

 .Electronic convex

  .Electronic linear

  .Electronic micro convex

  .4D

Transducer Types

 .3.5MHz Convex, D3C60L

  .7.5MHz Linear, D7L40L

  .6.0MHz Transvaginal, D6C12L

  .4.0MHz 4D volume, V4C40L

  .3.0Mhz Micro-Convex      (Cardiology)D3C20L

  .5.0MHz Micro-Convex  (Pediatric)D5C20L

Image Modes

  .B mode

  .THI mode (on convex probe)

  .M mode

  .PW (Pulse Wave Doppler)

  .CFM (Color Flow Mapping)

  .CPA (Power Doppler)

  .DPD (Directional Power Doppler)

  .4D (option)

  .Trapezoidal imaging (only for linear probe)

Display Mode

 .Quad/dual display (for B, CFM , CPA modes)

 .Duplex mode: B+CFM, B+PW, B+CPA,B/M

Display Annotation

  .Institution/Hospital name

 .Date/Time

  .Patient Name and Patient ID

  .System status (real-time or frozen)

  .Gray/Color bar

  .Cine guide

  .Scanning direction

  .Measurement summary window

  .Measurement results window

  .Probe type

  .Frequency

  .Application name

  .Menu indication

  .Trackball functions indication

  .Imaging parameters displayed on the screen

Standard Configuration

 .High resolution 19 Inch LCD display

  .4 active probe ports

  .Pulse Wave Doppler

 .Color Doppler Flow Imaging

 .Power Doppler Flow Imaging

  .Directional Power Doppler Flow Imaging

  .≥320G integrated hard disk

 .USB ports: 2 on keyboard and another 4 on back panel

.Ethernet port

  .Audio Stereo Output

 .Video Out

     -VGA signal*2

     -Video output (NTSC or PAL )

     -S-Video output (NTSC or PAL )

General measurement package

.Clinical measurement package

 .Multi-language screen display

  .DVD-RW driver

                 TM

.EASYVIEW         : image archive system

.Patient information management system

  .Building reporting system

  .AIO (Automatic Image Optimization)

.Intelligent Zoom

     -Real-time Zoom

     -Freeze Zoom

     -PIP Zoom

     -Pan Zoom

.Speckle Reduction Algorithm (SRA)

.Multiple Compound Imaging (MCI)

 .3.5MHz Convex probe, D3C60L

Software Options

 .i-ImageTM software package

DICOM 3.0

.4D software package

Hardware Option

.7.5MHz Linear probe, D7L40L

.6.0MHz Transvaginal probe, D6C12L

  .3.0Mhz Micro-Convex D3C20L

 .5.0MHz Micro-Convex D5C20L

.4.0MHz 4D volume probe, V4C40L and 4D module

 .Biopsy guide

Footswitch

Peripherals

.Video printer: SONY UP897MD
