Specifications
Steel Wire Shelf Welding Machine1.Function:Producing mesh
2.Voltage:380v
3.Current:50Hz
4.Rated capacity:100KVA
Steel Wire Shelf Welding Machine
1.Introduction of Automatic Welded Wire Mesh Machine
This machine adopts PLC program system and synchronous control technology . The welding time and separating welding is controlled by
numeric integrated circuit, which is with high control precision and stable function. In order to adapt the capacity of the clients',welding
transformers don't work at the same time but press at one time, welding repeatedly.The weft wire and longitude wire should be pre-staightened and pre-cut. The finished product fence panel is smooth,the error of oppsite angle line is small.
2.The Technical Parameters of Auto Welded Wire Mesh Machine :
Model |
DNW-CNC2000 |
DNW-CNC2500 |
DNW-CNC3000 |
||
Installed power(kva) |
7*125 |
9*125 |
11*125 |
||
System coltagte(v) |
380V 50Hz |
380V 50Hz |
380V 50Hz |
||
Control voltage(v) |
24V |
24V |
24V |
||
sh width |
2000 |
2500 |
3000 |
||
Line wire spacing |
≥100mm steplessly adjustable |
||||
Cross wire spacing |
≥100mm steplessly adjustable |
||||
Wire diameter(mm) |
5-12 |
5-12 |
5-12 |
||
Max.welding capacity |
12+12 |
12+12 |
12+12 |
||
Max.wlding speed(time/min) |
30-60 |
30-60 |
30-60 |
||
Max.welding spot nos.(group) |
21 |
26 |
31 |
||
Pressed air(MPa ) |
≥0.8 |
≥0.8 |
≥0.8 |
||
Wire feeding method |
Pre-cut |
||||
Caterconer accutracy |
≤2 |
≤2 |
≤2 |
||
Material |
galvanized wire, cold-rolled ribbed bar or low carbon steel wire |
||||
3. Steel Wire Shelf Welding Machine Pictures:
4.The Products that our machine Product:
About us :
“Anping Youjie Hardware Wire Mesh Co.,Ltd” is located in Anping County, where is the largest wire mesh distribution and production center of China.and enjoys the reputation of “Chinese Mesh and Netting County". Scientific, rigorous and trustworthy have accompanied by the growth of our corporation since it was founded over twenty years ago. And now “Youjie” has became an integrated enterprise with production, R&D, sales and trade.
We are the manufactory of the Welded wire Mesh Machine . Our goods have the high quantiy and reasonble price. Welcome the Visit us .
Our Factory:
