Specifications
Material: 200 series, 300 seriesDiameter: 0.02-5mm
Tolerance: +/-0.02%
Grade: SUS302,304,304L,316,316L
| Stainless steel wire |
Dlamete(mm) |
Standard |
|
Tolerance(mm) |
Max.Deviation(mm) |
|
0.32-0.45 |
+/-0.006 |
0.006 |
0.50-0.75 |
+/-0.006 |
0.006 |
0.80-0.95 |
+/-0.008 |
0.008 |
1.00-1.25 |
+/-0.010 |
0.010 |
1.30-1.50 |
+/-0.010 |
0.010 |
1.60-1.80 |
+/-0.015 |
0.015 |
2.0-2.5 |
+/-0.015 |
0.015 |
3.0-4.0 |
+/-0.015 |
0.015 |
Material: SUS302,304,304L,316,316L,etc
Characteerisics:
acid-resisting, alkali-resisting,heat-resisiting,corrosion-resisting, wire-drawing,
weaving of wire mesh, Uniform and beautiful surface condition without spots,
Excellent coil-forming ability,etc.
wire dia |
strengh tensile(Mpa) |
||
MM |
B |
C |
D |
0.2 |
1860-2260 |
2200-2600 |
2550-2940 |
0.45 |
1860-2260 |
2200-2600 |
2550-2940 |
0.5 |
1860-2260 |
2200-2600 |
2550-2940 |
0.55 |
1810-2210 |
2150-2550 |
2500-2890 |
0.6 |
1760-2160 |
2110-2500 |
2450-2840 |
0.65 |
1760-2160 |
2110-2500 |
2450-2840 |
0.7 |
1710-2110 |
2060-2450 |
2450-2840 |
0.8 |
1710-2060 |
2010-2400 |
2400-2840 |
0.9 |
1710-2060 |
2010-2350 |
2350-2750 |
1 |
1660-2010 |
1960-2300 |
2300-2690 |
1.2 |
1620-1910 |
1910-2250 |
2250-2550 |
1.4 |
1620-1910 |
1860-2210 |
2150-2450 |
1.6 |
1570-1860 |
1810-2160 |
2110-2400 |
1.8 |
1520-1810 |
1760-2110 |
2010-2300 |
2 |
1470-1760 |
1710-2010 |
1910-2200 |
2.2 |
1420-1710 |
1660-1960 |
1810-2110 |
2.5 |
1420-1710 |
1660-1960 |
1760-2060 |
2.8 |
1370-1670 |
1620-1910 |
1710-2010 |
3 |
1370-1670 |
1570-1860 |
1710-1960 |
3.2 |
1320-1620 |
1570-1810 |
1660-1910 |
3.5 |
1320-1620 |
1570-1810 |
1660-1910 |
4 |
1320-1570 |
1520-1760 |
1620-1860 |
6 |
1320-1570 |
1520-1760 |
1620-1860 |
