Specifications
mini cnc laser metal cutting machine1.500*500mm
2.Auto focus laser head
3.for circular tube and plate sheet
4.CE
mini cnc laser metal cutting machine for sheet metal 5050
Machine features:
1. Movable cross table makes more easy to cut smaller sheet.
2. Auto focus laser cutting head with “Laser-mech” USA, guarantee the right focus length.
3. Can workable for both small size materials and circular tube.
4. High precision, and thin cutting line
5. Able to cut high reflecting materials: Aluminum, Brass
YAG500W metal laser cutting machine parts:
Applicable industry:
Applied to electronic components , signage, tiny precision accessories perforated tube fittings, square profile processing and other high precision industry.
Technical Parameter:
Machine Model |
SIGN-5050-YAG500W |
Max Cutting area |
500*500mm |
Cutting thickness |
0.2-8mm |
Laser wavelength |
1064nm |
Laser type |
YAG |
Laser rated average power |
300-500W |
Power device injected power |
18KW |
Chiller |
7HP |
Transmission |
Imported high precision ball screw |
Driving way |
Imported servo motor |
X/Y Axis location accuracy |
0.05mm |
X/Y Axis repeat location accuracy |
0.05mm |
X/Y Axis moving speed Max |
30m/min |
Max Cutting speed |
2100mm/min |
Min Cutting line |
0.2mm |
Samples:
Packing:
SIGNCNC equipment after-sale service:
(1) Free technical support by mail, calling and MSN,SKYPE,YAHOO online.
(2) Free replace parts will send to you within machine warranty period.
(3) English manual and guide video with machine.
FAQ:
Please feel free to contact us for more information.
