metal and nonmetal laser cutting machine made in China/hobby metal laser cutting machine SIGN YAG 500W 1325
- 450 Set / Sets per Month
- Qingdao
- T/T Credit Card PayPal
- REBOUND CNC plasma cutting machinery with bevel head 30mm
- REBOUND cnc detachable gantry plasma and flame cutting machinery sheet
- Best price cnc detachable plasma cutting machinery for gas-plasma cutting
- helical rack and pinion cnc detachable plasma cutting machinery automatic high safety level
- pump inside air detachable plasma cutting machinery sliding work bench
- solenoid valve for detachable plasma cutting machinery lokermann high safety level
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | SIGN CNC |
Model Number: | YAG 500W 1325 | Voltage: | 380V | Rated Power: | 18kw |
Dimension(L*W*H): | 3.15*2.1*1.65m | Weight: | 1000KG | Certification: | CE |
Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
hobby metal laser cutting machine1.small cutting line, high precision
2.auto-focus laser head
3.Japan servo motor
4.DSP
hobby metal laser cutting machine
1. Technical parameters :
Machine Model | SIGN-1325 YAG-500w |
Max Cutting area | 1300*2500mm |
Laser type | YAG |
Laser power | 500W |
Type of cooling | Water cooling |
Maximum cutting | 0.2 – 6mm |
Laser wavelength | 1064 nm |
Laser rated average power | 300-500 W |
Power device injected power | 18 KW |
Water chiller | 7 HP |
X/Y Axis location accuracy | ±0.05 mm |
X/Y Axis repeat location accuracy | ±0.05 mm |
Min Cutting line | 0.2 mm |
Max Cutting speed | 2100mm/min |
Location area | 4.0 * 2.5 * 1.5m |
2. Machine features:
1. SIGN-YAG500W smaller cutting line, high precision.
2. Auto focus laser cutting head with 'LaserMech' UAS, guarantee the right focus length.
3. High precision ball screw with a perfect fuel injection systems, make sure a continuity and fluency transmisison.
4. Japanese servo motor make sure the cutting stable and cutting speed fast.
5. Water chiller high capacity provides stability during long-term operation.
6. Separate control box and DSP control makes it easier to manage the machine.
3. Applicable industry:
This machine is widely used in metal processing industry, for various metals, such as stainless steel, carbon steel, aluminum, copper, titanium plate, etc.
4. Payment method:
1. Delivery time: 15 days
2. Payment terms: 50% T/T payment deposit, 50% balance before delivery
3. Packing: one plywood case
4. Packing size: 21CBM
5. Warranty: 1 year
5. Machine accessories:
6. Samples:
1. 24 hour Technical support by phone, e-mail or MSN around the clock
2. Friendly English version manual and operation video CD disk
3.7-15 working days after down payment or full payment
4. Machine will be adjusted before it is delivered; operation disk/CD was included.
5. Our technician can give you remote guide online (Skype or MSN) if you have any question
6. Engineers available to service machinery overseas, seller and buyer discuss the charges
We are the professional YAG laser cutting machines supplier and have 5 years’ rich experience in this field.
SIGN CNC is the famous brand in China, We are the manufacturer and have own factory, if necessary, you can visit to our factory, we will give you a warm welcome.
We offer Laser Engraving Machine, Laser Cutting Machine, Stone Engraving Machine, Crafts Engraving Machine,Woodworking Engraving Machine,Advertising Engraving Machine, Laser Marking Machine, and Plasma Cutting Machine. Our machines have already found a good sale in Europe and all over the world.
1. Q: How do you send your machine?
A: We can send our machines by sea, land and rail way, or we can send the machine to your doors.
2. Q: This is my first time to use this machine, is it easy to operate?
A: There are guide videos that show how to use machine and English instruction book send to you with machine.
If there is still have any question, we will provide free professional guide for you until you could use machine well.
3. Q: If machine has any problem after I ordered, what should I do?
A: Free parts send to you in machine warranty period if machine have any problem.
Free after-sales service life for machine, please feel free contact us if your machine have any problem.
