Help CenterMean Well NES-350-24 Power Supply
Related Products
Power Supply
Model: NES-350-24
Maker: Mean Well
Input: 100-120VAC/ 7.0 A
200-240 VAC /4.0 A
Output: 24v/14.6A
Specification
| Output |
DC Voltage: 24V Rated Current: 14.6A Current Range: 0~14.6A Rated Power: 350.4W Ripple & Noise (max) : 150mVp-p Voltage ADJ. Range: 20~26.4V Voltage tolerance:±1.0% Line Regulation: ±0.5% Load Regulation: ±0.5% Setup, Rise Time: 1000ms, 50ms/230VAC 1000ms,50ms/115VAC at full load Hold up Time (typ): 20ms/230VAC 16ms/115VAC at full load |
| Input |
Voltage Range: 90 ~ 132VAC / 180 ~ 264VAC by switch 254 ~ 370VDC Frequency Range: 47 ~ 63Hz AC Current (typ): 7A/115VAC 4A/230VAC Inrush Current: 40A/115VAC 60A/230VAC Leakage Current: <3.5mA / 240VAC |
| Protection |
Overload: 105 ~ 135% rated output power Protection type : Constant current limiting, recovers automatically after fault condition is removed Over Voltage: 27.6 ~ 32.4V
Protection type :Shut down O/P voltage, re-power on to recover
Over Temperature: 90°C±5°C(3.3~7.5V); 85°C±5°C(12~15V); 80°C±5°C(24V);75°C±5°C(27~48V) (TSW1) Detect on case
Protection type : Shut down O/P voltage, recovers automatically after temperature goes down
|
| Function |
Fan on/off Control(typ): RTH2≥50°C FAN ON, ≤45°C FAN OFF (3.3 ~ 7.5V) RTH2 ≥55°C FAN ON, ≤50°C FAN OFF (12 ~ 48V)
|
| Environment |
Working Temp. : -20 ~ +60°C (Refer to output load derating curve) Working Humidity: 20 ~ 90% RH non-condensing Storage Temp. Humidity: -20 ~ +85°C, 10 ~ 95% RH Temp. Coefficient: ±0.03%/°C (0 ~ 50°C) Vibration: 10 ~ 500Hz, 3G 10min./1cycle, 60min. each along X, Y, Z axes |
| Safety |
Safety Standards:UL60950-1 approved Withstand Voltage: I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC / 25°C/ 70% RH |
| Others |
MTBF:234.3K hrs min. MIL-HDBK-217F (25°C) Dimension: 215*115*50mm (L*W*H) Packing: 1.07Kg; 12pcs/13.5Kg/0.92CUFT |
