Honeywell UDC 3300 Temperature Controller

Name: Honeywell UDC 3300 Temperature Controller
Brand: Honeywell
SKU: 118470147
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Honeywell

Model Number:

UDC 3300

Uni Marine Services Pte. Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Singapore

Delivery Detail:

Delivery time depends on order quantity.

Brand Name Honeywell

Model Number UDC 3300

Temperature Controller

Model: UDC 3300

Maker: Honeywell

Specification:

Design
Input Accuracy	±0.20 % of span typical (± 1 digit for display) Field calibratable to ± 0.05 % of span typical 15 bit resolution typical
Sampling Rate	Input sampled six times a second
Temperature Stability	± 0.01 % of Full scale / °c change typical
Input Signal Failure Protection	Thermocouple Inputs: Upscale or downscale burnout Burnout Current: 0.13 microamps Failsafe Output Level: Configurable 0-100 %
Input Impedance	4-20 Milliampere Input: 250 ohms 0-10 Volt Input: 200k ohms All other : 10 megohms
Maximum Lead Wire Resistance	Thermocouples: 100 ohms/leg 100, 200, and 500 RTD: 100 ohms/leg 100 ohm Low RTD: 10 ohms/leg
Stray Rejection	Common Mode AC (50 or 60 Hz): 120 dB (with maximum source impedance of 100 ohms) or ± 1 LSB (least significant bit) whichever is greater with line voltage applied. DC: 120 dB (with maximum source impedance of 100 ohms) or a ±1 LSB whichever is greater with 120 Vdc applied. DC (to 1 KHz): 80 dB (with maximum source of impedance of 100 ohms) or ±1 LSB whichever is greater with 50 Vac applied. Normal Mode AC (50 or 60 Hz): 60 dB (with 100 % span peak-to-peak maximum)
