Help CenterDrop Forged Fixed Coupler Ringlock Scaffolding
Related Products
-
Metal Ringlock Scaffold for ConstructionsUS$ 10 - 100MOQ: 10 Sets -
Galvanised Ringlock Scaffolding for Construction,best Products Ringlock Scaffolding,galvanised Ringlock ScaffoldingUS$ 10 - 100MOQ: 10 Sets
-
Galvanized Ringlock Scaffolding for High Rise BuildingUS$ 10 - 100MOQ: 10 Sets
-
Q235 Tube Steel Ringlock Scaffolding for Construction,Heavy Load Cuplock ScaffoldUS$ 10 - 100MOQ: 10 Sets
-
Scaffolding Cast Steel Ledger End, Scaffold Ringlock LedgerUS$ 10 - 100MOQ: 10 Sets
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Ringlock scaffolding uses a simple, unique and bolt-free connection technology.
Sliding the wedge head over the rosette and inserting the wedge into the opening immediately secures the component. There is still sufficient play to secure the other end of the ledger.
A hammer blow to the wedge transforms the loose connection into a superbly strong structurally rigid one. The face of the wedge head is now precisely positioned against the standard.
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Types of scaffolding material Hot sale can be customized by drawings,below is our standard typs.
Best selling scaffolding ringlock with Q235 Q345 galvanized
| Product Name | Types of scaffolding material Hot sale | ||||
| Brand Name | YS | ||||
| technology | fully automatic circular seam welding | ||||
| Payment | T/T;L/C;and so on | ||||
| Customization | Can be made by drawings | ||||
Best selling scaffolding ringlock with Q235 Q345 galvanized
| Model | Specifications | Texture | Weight/kg | |
| Vertical | YS-LA-250 | Φ60*3.2*250 | Q345B | 2.65 |
| YS-LA-500 | Φ60*3.2*500 | Q345B | 3.75 | |
| YS-LA-1000 | Φ60*3.2*1000 | Q345B | 6.65 | |
| YS-LA-1500 | Φ60*3.2*1500 | Q345B | 9.6 | |
| YS-LA-2000 | Φ60*3.2*2000 | Q345B | 12.5 | |
| YS-LA-2500 | Φ60*3.2*2500 | Q345B | 15.5 | |
| YS-LB-250 | Φ48*3.2*250 | Q345B | 1.89 | |
| YS-LB-500 | Φ48*3.2*500 | Q345B | 2.95 | |
| YS-LB-1000 | Φ48*3.2*1000 | Q345B | 5.3 | |
| YS-LB-1500 | Φ48*3.2*1500 | Q345B | 7.64 | |
| YS-LB-2000 | Φ48*3.2*2000 | Q345B | 9.9 | |
| YS-LB-2500 | Φ48*3.2*2500 | Q345B | 12.3 | |
| Ledger | YS-SG-300 | Φ48*2.5*240 | Q235B | 1.4 |
| YS-SG-600 | Φ48*2.5*540 | Q235B | 2.3 | |
| YS-SG-900 | Φ48*2.5*840 | Q235B | 3.2 | |
| YS-SG-1200 | Φ48*2.5*1140 | Q235B | 4.1 | |
| YS-SG-1500 | Φ48*2.5*1440 | Q235B | 5 | |
| YS-SG-1800 | Φ48*2.5*1740 | Q235B | 5.9 | |
| YS-SG-2100 | Φ48*2.5*2040 | Q235B | 6.8 | |
| YS-SG-2400 | Φ48*2.5*2340 | Q235B | 7.7 | |
| U-head Jeck | YS-T-550 | Φ48*5.0*550 | Q235B | 4.38 |
| Base Jeck | YS-DT-550 | Φ48*5.0*550 | Q235B | 3.53 |
| Vertical Diagonal Brace | YS-XG-600*1500 | Φ33*2.3*1606 | Q195 | 3.92 |
| YS-XG-900*1500 | Φ33*2.3*1710 | Q195 | 4.1 | |
| YS-XG-1200*1500 | Φ33*2.3*1859 | Q195 | 4.4 | |
| YS-XG-1500*1500 | Φ33*2.3*2042 | Q195 | 4.7 | |
| YS-XG-1800*1500 | Φ33*2.3*2618 | Q195 | 5.7 | |
| YS-XG-2100*1500 | Φ33*2.3*2833 | Q195 | 8.22 | |
| Model | Length | Width | Height | |
| Steel Plank With Hook | YS-TB-240*45*900 | 0.9 | 240 | 45 |
| YS-TB-240*45*1200 | 1.2 | 240 | 45 | |
| YS-TB-240*45*1500 | 1.5 | 240 | 45 | |
| YS-TB-240*45*1800 | 1.8 | 240 | 45 | |
| YS-TB-240*45*2100 | 2 | 240 | 45 |
Best selling scaffolding ringlock with Q235 Q345 galvanized
| Steel Stair | Model | Length | Width | Height | Texture | Surface treatment |
| YS-LT-2.1*1.5*0.8 | 2.1 | 1.5 | 0.8 | Q235B | Hot dip galvanizing | |
| YS-LT-2.1*2.0*0.8 | 2.1 | 2 | 0.8 | Q235B | Hot dip galvanizing |
Best selling scaffolding ringlock with Q235 Q345 galvanized
Ringlock Scaffolding Eight A benefits
A Save time during assembly and dismantling thanks to bolt-free connection technology.
A Safe and simple one-man assembly.
A No loose parts.
A Very little material required.
A Maintenance free and always ready for use.
A Low weight of individual parts.
A Tried and proven range of parts.
A Economic and versatile design that convinces.
Other advantages of ringlock scaffolding
The result of ringlock scaffolding superior design:
Up to 8 connections can be made in the structurally ideal ringlock scaffolding connector on one level and at various angles. Connections are provided in ringlock scaffolding standard dimensions of 50 cm on all ringlock scaffolding standards. The flat rosette prevents clogging with dirt ofwhatever type.
Ingenious ringlock scaffolding connection technology:
The four small punchedout openings in the rosette automatically centre the ringlock scaffolding ledger at right angles –the four large openings allow the angle of alignment to be selected.
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanizedBest selling scaffolding ringlock with Q235 Q345 galvanized
Types of scaffolding material Hot sale Larvish Appliacation
Economic support scaffolding
Scaffolding for formworkers and steelfixers
Façade scaffolding
Birdcage scaffolding
Stairway access
Mobile work scaffolding
Tranches and emergency bridges
Best selling building scaffolding with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Welcome to visit our factory,and the third party certification is available.Other authentication require please contact us.
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Types of scaffolding material Hot sale packing: 1) with plasctic thin film; 2) packed by steel strips; 3) woven cloth.
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Best selling scaffolding ringlock with Q235 Q345 galvanized
Clients mainly care about questions:
Best selling scaffolding ringlock with Q235 Q345 galvanized
| Q1:Are you a trade company or a manufacturer? |
| A:We are the integrated industrial and trade enterprise. We are manufacture for almost 12 years,supply for 5 trading companies,and we established our own trading office in the last 2 years. |
| Q2:Are you have customized service? |
A:Yes,Metal welding customization products are one of our large part hot selling type,Stricted producine by your drawings.We own a whole technical team support of this. |
| Q3:Can you supply samples for our reference? |
| A:Yes,free samples for standard type.Special type may charge a little. |
| Q4:When I want your price,what parameters should I tell you? |
| A:Wall thickness;vertical and ledger length & OD;Base Jack size;and Drawings if customized. |
