High Speed Lamination Machine

Name: High Speed Lamination Machine
Brand: HUANA
SKU: 118442383
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Food, Beverage, Other, Food, Beverage, Machinery & Hardware

Packaging Type:

Film

Ruian Huana Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Port China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Food, Beverage, Other, Food, Beverage, Machinery & Hardware

Packaging Type Film

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Mechanical

Voltage 380V, 3Phases, 50HZ or according to customer

Power 40-80KW

Place of Origin Zhejiang, China

Brand Name HUANA

Model Number FG-A/FG-B/FG/C

Dimension(L*W*H) 12000*2100*2500mm

Weight 12Tons

Certification CE Certification

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Laminating width: 800mm-1600mm
Max.machine speed:220/min
It is suitable for the film/film,film/aluminum,film/paper lamination

Main features:

1-Lamination and coating adopts double inverter motors.

2-Dry box tension controlling adopt pressure sensor automatically adjusting.

3-The first unwinding station adopts photoeyes EPC controlling system, the second unwinding station adopts two stations (double unwinder)

4-Lamination and coating adopts air-cylinder pressing.

5-Rewinding unit adopts moment motor(torque motor) to control the tension.

Parameters:

Model	FG-B800	FG-B1000	FG-B1100	FG-B1200
Laminating Material	Plastic film, Paper, aluminium foil, compound film etc.
Laminating layer	2layers	2layers	2layers	2layers
Max. width of lamination	800mm	1000mm	1100mm	1200mm
Lamination speed	90-100m/min	90-100m/min	90-100m/min	90-100m/min
Max. rewinding/unwinding diameter	600mm	600mm	600mm	600mm
Dry box temperature available	100°C	100°C	100°C	100°C
Total Power	38KW	45KW	48KW	52KW
