steel adjustable scaffolding strut
- 5000 Metric Ton / Metric Tons per Month
- Xingang port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
Place of Origin | Tianjin, China | Brand Name | Yusheng | |
Model Number | Props |
Product Description
HEAVY DUTY STEEL POST SHORING PROP
Adjustable Steel Shoring Props is widely used in constructional formwork supporting, compare to wooden shoring prop, steel shoring prop has higher loading capacity, longer service life, more service cycle, safe, stable and more efficient. To be specific:
1 Adjustable Steel Shoring Props bears reasonable force,so it will get higher loading capacity,that will reduce the total amount to save constructional cost.
2 Adjustable Steel Shoring Props no need to add horizontal bracing,the props and tripod make a whole setup that becomes the base of the whole system. The support system could keep vertical and accuracy,so that could save both man-hour and work hour.
3 Various surface treatment, include,galvanizing, painting, powder coating. High quality surface treatment will extend the using time.
4 Yuanheng Sanctuary steel trading company could supply integrate service, we could customize adjustable length, surface treatment, we also could supply the most reasonable project according to your budget and constructional environment.
Production Name | Adjustable Steel Shoring Props |
Thickness | 3.5mm 3.25mm 3.0mm 2.5mm 2.2mm 2.0mm,etc |
Length | 1.6-2.9m; 1.8-3.8m; 2.0-3.6m; 2.59-3.95m; 2.5-4.5m; 3.0-5.0m; 3.2-4.87m(customization available) |
Floor/roof | 120*120*4mm 120*120*5mm 120*120*6mm 140*140*6mm 9 shape pin, Wire rope pin,allowed all color. |
Load Bearing | 3.5T or more |
Standard | GB, ANSI, ASME, ASTM, JIS, DIN, BS, EN |
Material | Q195,Q235, Q345 |
Package | in pallets or in bundle or in bulk |
Type | heavy duty or light duty |
Application | slab or formwork supporting |
type | adjustable height | Outter Tube | Inner Tube | Weight | 20ft container | surface |
(mm) | (mm) | (mm) | (kgs) | (pcs) | ||
Spanish-style | 800-1400 | 48*1.6*765 | 40*1.8*835 | 4.74 | 3500 | Varnished; Spray paint; Plastic spraying. Electric galvanizing; Hot dip galvanized |
1600-3000 | 48*1.6*1600 | 40*1.8*1600 | 7.57 | 2200 | ||
2000-3500 | 48*1.6*1710 | 40*1.8*2000 | 8.45 | 2000 | ||
2200-4000 | 48*1.6*2000 | 40*1.8*2200 | 9.32 | 1750 | ||
Italian style | 1800-3100 | 56*1.6*1510 | 48*1.8*1800 | 9.36 | 2100 | |
2000-3600 | 56*1.6*1750 | 48*1.8*2000 | 10.29 | 2000 | ||
2200-4000 | 56*1.6*2010 | 48*1.8*2200 | 11.26 | 1750 | ||
the Middle East and German type | 1400-2700 | 60*2.0*1340 | 48*2.0*1400 | 9.45 | 2300 | |
2000-3500 | 60*2.0*1540 | 48*2.0*2000 | 11.38 | 2000 | ||
2200-4000 | 60*2.0*1840 | 48*2.0*2200 | 12.7 | 1750 | ||
3000-5500 | 60*2.0*2540 | 48*2.0*3000 | 16.51 | 1500(40ft) |
Adjustable Steel Shoring Props packing:
1.bundle with steel strip
2.packaged by waterproof paper
3.packaged by plastic paper
4.bundle in steel pallets
Clients mainly care about questions:
Q1:Are you a trade company or a manufacturer? |
A:We are the integrated industrial and trade enterprise. We are manufacture for almost 12 years,supply for 5 trading companies,and we established our own trading office in the last 2 years. |
Q2:Do you have customized service? |
A:Yes,Metal welding customization products are one of our large part hot selling type,Stricted producine by your drawings.We own a whole technical team support of this. |
Q3:Can you supply samples for our reference? |
A:Yes,free samples for standard type.Special type may charge a little. |
Q4:When I want your price,what parameters should I tell you? |
A:Wall thickness;vertical and ledger length & OD;Base Jack size;and Drawings if customized. |
