Telescopic steel shoring prop, acrow steel post shore
High quality Australian type acrow props is widely used in constructional formwork supporting, compare to wooden shoring prop, steel shoring prop has higher loading capacity, longer service life, more service cycle, safe, stable and more efficient. To be specific:
1 Steel shoring prop bears reasonable force,so it will get higher loading capacity,that will reduce the total amount to save constructional cost.
2 Steel shoring props no need to add horizontal bracing,the props and tripod make a whole setup that becomes the base of the whole system. The support system could keep vertical and accuracy,so that could save both man-hour and work hour.
3 Various surface treatment, include,galvanizing, painting, powder coating. High quality surface treatment will extend the using time.
4 Yuanheng Sanctuary steel trading company could supply integrate service, we could customize adjustable length, surface treatment, we also could supply the most reasonable project according to your budget and constructional environment.
Acrow props normal standard
| Production Name | Adjustable Steel Prop Scaffolding |
| Thickness | 3.5mm 3.25mm 3.0mm 2.5mm 2.2mm 2.0mm |
| Length |
1.6-2.9m; 1.8-3.8m; 2.0-3.6m; 2.59-3.95m; 2.5-4.5m; 3.0-5.0m; 3.2-4.87m(customization available) |
| Floor/roof |
120*120*4mm 120*120*5mm 120*120*6mm 140*140*6mm 9 shape pin, Wire rope pin,allowed all color. |
| Load Bearing | 3.5T |
| Standard | GB, ANSI, ASME, ASTM, JIS, DIN, BS, EN |
| Material | Q195,Q235, Q345 |
| Package | in pallets or in bundle or in bulk |
| Type | heavy duty or light duty |
| Application | slab or formwork supporting |
| type | adjustable height | Outter Tube | Inner Tube | Weight | 20ft container | surface |
| (mm) | (mm) | (mm) | (kgs) | (pcs) | ||
| Spanish-style | 800-1400 | 48*1.6*765 | 40*1.8*835 | 4.74 | 3500 |
Varnished; Spray paint; Plastic spraying. Electric galvanizing; Hot dip galvanized |
| 1600-3000 | 48*1.6*1600 | 40*1.8*1600 | 7.57 | 2200 | ||
| 2000-3500 | 48*1.6*1710 | 40*1.8*2000 | 8.45 | 2000 | ||
| 2200-4000 | 48*1.6*2000 | 40*1.8*2200 | 9.32 | 1750 | ||
| Italian style | 1800-3100 | 56*1.6*1510 | 48*1.8*1800 | 9.36 | 2100 | |
| 2000-3600 | 56*1.6*1750 | 48*1.8*2000 | 10.29 | 2000 | ||
| 2200-4000 | 56*1.6*2010 | 48*1.8*2200 | 11.26 | 1750 | ||
|
the Middle East and German type |
1400-2700 | 60*2.0*1340 | 48*2.0*1400 | 9.45 | 2300 | |
| 2000-3500 | 60*2.0*1540 | 48*2.0*2000 | 11.38 | 2000 | ||
| 2200-4000 | 60*2.0*1840 | 48*2.0*2200 | 12.7 | 1750 | ||
| 3000-5500 | 60*2.0*2540 | 48*2.0*3000 | 16.51 | 1500(40ft) |
Customization Service
1 The thickness of outer tube and inner tube could customized as required.
2 The plate could be customized to different types as you require.
3 All the styles could be galvanized,painted,or powder coated.
4 The cup nut could be threaded or rolling threaded
Acrow props package
1.bundle with steel strip
2.packaged by waterproof paper
3.packaged by plastic paper
4..bulk in container directly
Clients mainly care about questions:
| Q1:Are you a trade company or a manufacturer? |
| A:We are manufacture for almost 12 years,supply for 5 trading companies,and we established our own trading office in the last 2 years. |
| Q2:Are you have customized service? |
| A:Yes,we supply both the standard steel pipe,scaffolding, and some customized type as your drawings.We own a whole technical team support of this. |
| Q3:Can you supply samples for our reference? |
A:Yes,free samples for standard type.Special type may charge a little. |
| Q4:When I want your price,what parameters should I tell you? |
| A:Size,Materials,Pictures,Standards,Quantities,and Drawings if customized. |
| Q5:What are you main products. |
|
|
Pre-sale: 7*24 hours on line service,anything anytime you want to know more about our products,please contact us.A whole technical & design team supporting customized orders. on-sale: One special sale servicer for you own,strict for all the producing & delivery steps,and update to you in the real time. After-sale: A 5 person department mainly solve this kinds of issues,aiming to slove your problems well. |
