Help CenterSolar Charge Controller IP31 Power Tarom 4545 (Steca Series Charger Controller)
Related Products
Specifications
1.Solar Charge Controller/Solar Controller/Solar Regulator2.Hybrid controller
3.PWM control
4. Automatic load reconnection
Specification of Solar Charge Controller IP31 Power Tarom 4545 (Steca series Charger Controller)
Steca Tarom 4545, 4545-48
The new design for the Steca Tarom sets new standards in this power class. A graphic display informs the user about all important system data and enables configuration and adjustment of the controller to the specific requirements of the individual system.
Numerous clever functions allow the user to adjust the controller to the particular features of the system in question. Thanks to the significantly improved state of charge determination, the system is optimally controlled and the batteries are protected. The Steca Tarom charge controller is the best choice for system sizes of up to 2,400 Wp at three voltage levels (12 V, 24 V, 48 V).
The integrated data logger stores all important system data which can be read via an open Steca RS232 interface. As an option, an external temperature sensor can also be connected.
Two additional switching contacts can be freely configured as a timer, a night light function, to start generators or as surplus management.
Product features:
- Hybrid controller
- State of charge determination (SOC)
- Automatic detection of voltage
- PWM control
- Multistage charging technology
- Load disconnection depending on SOC
- Automatic load reconnection
- Temperature compensation
- Common positive or negative grounding on one terminal
- Innovative data logger
- Night light function
- Integrated self test
- Monthly maintenance charge
- Integrated energy meter
- Two configurable multifunctional contacts
Electronic protection functions:
- Overcharge protection
- Deep discharge protection
- Reverse polarity protection of module and battery
- Reverse polarity protection by internal fuse
- Automatic electronic fuse
- Short circuit protection of load and module
- Open circuit protection without battery
- Reverse current protection at night
- Overtemperature and overload protection
- Battery overvoltage shutdown
Displays:
-
Multifunction graphical LCD display with backlighting
for operating parameters, fault messages, self test
Operation:
- Simple menu-driven operation
- Programming by buttons
- Manual load switch
Interfaces:
- Open Steca RS232 interface
Options:
- External temperature sensor
- Alarm contact
Certificates:
- Compliant with European Standards (CE)
- Made in Germany
- Developed in Germany
- Manufactured according to ISO 9001 and ISO 14001
Company Profile:
|
In the course of cooperation with domestic and foreign outstanding enterprises that EastWest learned from their advanced technology and management experience. We have high quality products, professional technology and 10 years of experience with application all over the world electronic power and solar energy market, all of these had proved our strength. |
||
10 years of EastWest Energy - History and Development | |
1997 |
The company is founded. It assembles inverters, and develops and produces power electronics products. |
2000 |
The company has developed into a significant professional supplier of inverters and solar power system. |
2001 |
The company is authorized officially as Germany Steca’s technical support center. EastWest and STECA are expanded to cooperate in China and international for solar project. |
2002 |
EastWest and IWATANI (Japanese) cooperation won the bidding for “Japan No-Project Aid Mongolia” of “Solar Home System” project. EastWest and Steca provided 2,200 sets electrical power distribution systems and solar charge controllers. |
2003 |
EastWest won the bidding of “The Electronic Power Distribution System Project” for “Solar Home System” of Mongolia Post and Telecommunication Department (PTA). EastWest and Steca provided 8,000 sets electrical power distribution systems and solar charge controllers. |
2004 |
The company won the bidding of “Solar Home System” of “China government No-Project Aid Mongolia Government”, provided 22,000 electrical power distribution systems. |
2005 |
The company is expanded to include product ranges for inverters, back-up power systems, solar power systems and solar electronics with own product line. |
2006 |
The company export 500 sets solar power systems to Mozambique for the project of World Bank(WB). |
2007 |
The company is expand into a full-service inverters, back-up power system and solar system service provider. |
