Anon Large Scale Grinder

Anon Large Scale Grinder photo-1
Anon Large Scale Grinder photo-2
Anon Large Scale Grinder photo-3
Anon Large Scale Grinder photo-4
Anon Large Scale Grinder photo-5
Anon Large Scale Grinder photo-6
US$ 12,000 - 16,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hubei, China
Brand Name:
Anon
Payment & Shipping
Payment Methods:
Port of Shipment:
any Port of China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Hubei, China
Brand Name Anon
Model Number ANON 20-30T Rice Mill Set
Production Capacity 20-30ton per day
Voltage 380v,50hz,3phase
Power(W) 72.1kw
Dimension(L*W*H) 860*190*372cm
Certification ISO9001 CE GS
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Anon large scale grinder
2.high quality,less broken rice
3.voltage 380v or customized
4.ISO9001 certification

Anon large scale grinder

Product Description

Anon large scale grinder

Specifications of 20-30TPD rice mill:   Anon large scale grinder

1.  Model:20-30T   grain milling equipment

2. Output of white rice: 20-30ton/day (24hours).

3.Total Power of standard equitpment: 37.6kw (no polisher,no color sorter,no electric scale).

4.size of standard dimension: 750x190x372cm.

5. Standard equitpment list: cleaner/husker/paddy separator/rice whitener (no optional items)

6. Voltage: 380V, 50Hz, 3phase. Customed voltage is available, such as 440V or 480V.

7.  Optional item: Polisher/CCD color sorter/electrical scale/Rice storage bin/ Diesel generator etc.



Main Technical Specifications of  Anon large scale grinder



Capacity
Power
Overall dimensions
(L×W×H  mm)
20-30T/D
37.6KW
7500×1900×3720

S/N

Model

Capacity(t/h)

Power  (kw)

Qty(pcs/set)

1

Combined Cleaner

1.5-2.0

0.2×2

1

2

Husker

1.75-2.2

5.5

1

3

Paddy Separator

1.3-2.0

1.1-1.5

1

4

Rice Whitener

1.1-1.5

22

1

5

Rice Grader

1.0-1.5

1.1

1

6

Elevator



0.75×5

5

7

Blower-4-72No.3.6A



3

1

8

Blower-3.8#



1.1

1

9

Cyclone-300



1

10

Control Panel for 20-30t/d Equipment



1

11

Steel Operating Platform



1

12

Accessories                                          (Including Collecting Dust System and its pipe)



1















































1.This complete rice millmachine is used to process long rice, is an unconventional plant, can make both white rice and brown rice.



2, Combined cleaner  can remove all the impurities and unfilled grains and stones from raw paddy.



3,Paddy husker shelling to get brown rice.



4,Paddy separator is used to separate the unhusked paddy from brown rice.



5,Rice Whitener can remove the bran layer to get white rice from brown rice.



6, Rice Grader separate the rice into several classes , such as head rice ,big broken ,medium broken ,small broken.

Features of Anon rice mill:   Anon large scale grinder

1.    Full automatic compelet production line, with latest technology

2.    Low noise and consumption, compact structure

3.    Easy to operate continuous operation.

4.    High output and low broken rate.

5.    Reasonable price.

6.    Professional Anon work team. Above solution is standard solution according to Chinese paddy features. Anon engineer will change solution to fit client’s local paddy charator and environment. E.g. for Philippine, paddy is wet more than 15% humidity, engineer suggest large capacity of husker series.

 Anon large scale grinder



Sample Project in Myanmar:   Anon large scale grinder



Company Information

 We reconmmend our customer provide your local eletric power information (e.g voltage:380v ; frequency:50hz , 3phase) and capacity of the machine required (e.g Paddy 1ton/hour or polished white rice 1ton/hour)
