heat insulation paper transformer insulating paper
1.What is your MOQ?
A :MOQ may vary by customer's special requirement; we try our best to meet your business requirement.
2.Can you provide sample?
A: Yes, we can offer sample , and some samples are free
3. Can you delivery by express?
A: Yes, we can delivery by any express
4.Can you accept OEM ?
A: YES! We can according your demand to produce.
5. How to solve the quality problems?
A:If the products are not conform to customer samples or have quality problems, our company will be responsible.
6. what‘s your regular practice concerning terms of payment?
A: Payment terms :T/T 30%-50% deposit after order confirm ,the balance after goods ready before shipping or L/C, or Western Union for small amount. Or PAYPAL.
7. How long does it usually take you to make delivery?
A: Lead time: Normally about 10 days after deposit received
heat insulation paper transformer insulating paper is manufactured by refractory fiber with high purity which is used in high-temperature insulating fields. The advance manufacturing technology makes the distribution of fiber be very even and the paper’s thickness and storage can also be controlled strictly.It is made of refractory ceramic fiber with a little bond which is selected scientifically and controlled strictly. The bond will be completely burnt during the use. The product does not contain asbestos and is perfect material for sealing and insulating.
Easy to cut,wrap or form
Low thermal conductivity and heat storage
Excellent thermal shock and flame resistance
Light weight
Resilient
Excellent hydrophobic property
Good dielectric strength
Free of asbestos
heat insulation paper transformer insulating paper
Classification Temperature(ºC) |
1260(2300℉) |
1400(2552℉) |
Bulk density (Kg/M3) |
200+/-15 |
200+/-15 |
Organic content(%) |
6-8 |
|
Thermal conductivity(w/m.k) Density(200Kg/m3) |
200 ºC(392℉) 0.075-0.085 |
|
400 ºC(752℉) 0.115-0.121 | ||
600 ºC(℉) 0.165-0.175 | ||
Moisture Content(%) |
≤1 |
≤2 |
Chemical composition(%) |
AI2O3 45-46 |
38-47 |
SiO2 51-52 |
51-52 |
|
ZrO2 |
15-17 |
|
Product specification mm |
60000x1220x1,60000x610x1 30000x1220x2,30000x610x2 20000x1220x3,20000x610x3 15000x1220x4,15000x610x4 12000x1220x5,12000x610x5 10000x1220x6,10000x610x6 |
|
1.Asbestos paper replacement
2.Investment cast mold wrap insulation
3.One-time consumable insulating applications
4.Back-up lining for metal troughs
5.Hot top lining
6.Applications where low binder content is required
7.Thermal and electrical insulation
8.Upgrade for fibreglass paper and blanket products
We are one of the leading ceramic fiber manufactures and have the long-term experience
15 production lines high quality equipment and big turnout, which can satisfied your market needs.
Responsible production lead to high quality.
Fast delivery and favorable price
The best package
You can not only get the best products money can buy, but also get our experience and solution, we could to be the best friend and the mutual benefits in this field with each other.
Any quesiton please contact me,hope we can built long term cooperation in the near future.
