Help CenterBarcode Scanner Module XL-1059
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
Other, laser
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
OEM Scanner Module XL-1035NegotiableMOQ: 10 Pieces -
Factory Price ! Laser Barcode Scanner Module XL1035NegotiableMOQ: 100 Pieces
-
Laser Barcode Scanner Module XL1035NegotiableMOQ: 100 Pieces
-
OEM Barcode Reader Module XL1035NegotiableMOQ: 100 Pieces
-
Hot 2016 New Product Data Collector Barcode Scanner XL-868NegotiableMOQ: 1 Piece
Products Status
Stock
Type
Barcode Scanner
Scan Element Type
Other, laser
Colour Depth
32 Bit
Interface Type
USB, COM, PS/2
Scan Speed
100 tiems/ second
Brand Name
SUNLUX
Model Number
XL-1059
Place of Origin
China
Specifications
1. CPU: 32 bit ARM microprocessor2. Decoding rate: 100 times/s
3. small body
4. suit for POS
OEM Barcode Scanner module XL1059
1. CPU: 32 bit ARM microprocessor, super decoding ability
2. Decoding rate: 100 times per second
3. customer setting: Barcode setting mode, easy to operate
4. Scan Depth of field up to 350mm
5. Full independent intellectual property rights
Performance Parameter
| Functionality Item | Parameter |
| Type of illuminant | 650nn laser |
| Use type | handfree |
| Bit error rate (BER) | 1/5 million |
| Safety performance | Meet the Grade II National Criteria for Laser Safety |
| Barcode types | EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber,Industoal 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI, Chinese postcode etc. |
| Supported interfaces | RS232, PS2 keyboard, USB, etc. |
| Scanning method | automatic |
| Transmission rate | RS232 Baudeate:2400-38400 |
| Resolution (pcs0.9) | 0.10mm(4mnl) |
| Depth of field | 10- 350mm (pos09 density 0.25) |
| decode speed | 100 times/second |
| Reading preciseness | 0.40-0.825mm |
| Reading distance | 10-520mm |
|
Reading angle of elevation |
60° |
| Reading angle of dip | 45° |
| Operating temperature | -20°C-45°C |
| Storage temperature | 20°C-45°C |
| Operating humidity | 5%-85% |
| Storage humidity | 5%-85% |
| Power voltage | 5V |
| Working current | 57mA |
| Static current | 36mA |
| Fall test | 100 times/1.5m |
| Light intensity | Daylight, 4000Lux |
| Electromagnetic interference | Complying with en50081, par1 criteria |
| External electromagnetic interference resistance | Complying with en50081, par1criteria |
| Dustproofing and waterproofing | Complying with en50081, par1 criteria |
| Exterior dimension | Length*Width*Height: 49mm*42mm*25mm |
| Materials | elctonic |
| Weight | 33g |
