barcode reader module XL1035 :
1. Small body.
2. Simple installation.
3. Reading depth of field.
4. contain barcode scanner engine and decoder
5. Standard 8 pins interface.
6. Easy to be integrated with all kinds of OEM equipments.
7. Can read all of standard 1D barcodes.
Performance
Type of illuminant: |
Visible laser diode (650nm) |
Reading preciseness: |
0.10mm (4mil) |
Reading speed: |
48 times/second |
Reading distance (Adjustable): |
52cm |
Reading angle of dip: |
∠ 45º |
Reading angle of elevation: |
∠ 60º |
Power voltage: |
DC5V |
Working electricity: |
30mA |
Humidity: |
5% ~ 95% (With condensation) |
Light intensity: |
Daylight, 7000LUX |
Minimum printing contrast: |
While at 650nm, the minimum absolute black/light contrast is 20% |
Exterior dimension (W×D×H): |
40mm×33mm×17mm |
Weight: |
34g |
Interfaces: |
8-Pin ZIF Adapter, Industry standard output |
