two position push button with light
♦ PARAMETER
| Voltage(max) | 660V |
| Ui Rated Insylation Voltage | AC660V 50HZ |
| Ith Conventional Current | 10A |
| Contact Resistance | ≤50mΩ |
| Protective | IP65 |
| Insulation Material | PA66 |
| Operdtion Category | AC-15 DC-13 |
| Installation Height | ≤2000M |
| Polution Class | 3 |
| Operation Temperature | -25°c~+55°c |
| Viberation Durability | 10~200HZ 1mm.10g |
♦ PRODUCT DETAILS
Models showing
Utility Electrical Co., Ltd |
|
Utility Electrical Co., Ltd., A specialized supplier of terminal blocks, cable gland, push button, and indicator light since 1990.With more than 20 years export experience,we have firmly believed in the idea of consistent quality, service, honesty, and responsibility, which is also our policy to satisfy our customers with the most competitive price, the excellent quality, and the best service. We have profound OEM/ODM experience with domestic and world-famous enterprises.If you are interested in any of our products, please feel free to contact with us immediately. We look forward to building a long-term cooperation relationship and bringing a mutual benefits with you.
|
Factory |
Our company founded in 1990, is a professional manufacturer and supplier of terminal blocks, cable gland, push button, and indicator light . Our factory, which is located in Wenzhou,Zhejiang Province, China, has been built to support our continuously expanding business.At present, we are extending our business to North America, Middle America, South America, Europe, Asia, Australia, and Far East countries.
.......................................................................................................................................................................................................
Certificates |
Up to now,we awarded CE UL VDE RoHS CCC CQC certifications.
1. The quoted price is always valid for 15 days due to the fluctuation of raw material cost. Please feel free to contact us for the catalogue or prices.
2. Please kindly inform us which items you are interested & the best price will be provided you upon receipt of your new inquiry asap.
3. Samples will be offered to you for our future cooperation.
