Product Details
Place of Origin: | Beijing, China | Brand Name: | Vmaxpower | Model Number: | MUL-6M-60M-36 |
Specification: | Normal | Application: | Home | Output Voltage (V): | 110V/220V |
Load Power (W): | 60w | Solar Power (W): | 60W | Work Time (h): | 8 Hours |
Product Description
Model No.: MUL-6M-60M--36
Performance
High efficiency.Monocrystalline silicon solar cells with high transmission and textured glass deliver a module efficiency of up to 16.5%.minimizing installation costs and maximizing the KWH output of your system per unit area
Tight positive power tolerance of 0W to +5W ensures you receive modules at or above nameplate power and contributes to minimizing module mismatch losses leading to improved system yield
Top ranking in the TUV rheinland energy yield test and the PHOTON test demonstrates high performance and annual energy production
Reliability
Tests by independent laboratories prove that Vmaxpower Solar modules:
Full conform to certification and regulatory standards
With stand wind loads of up to 2.4KPa and snow loads of up to nfirming mechanical stability
Successfully endure ammonia and slat-mist exposure at the highest severity level.ensuring their performance in adverse conditions
Junction box and bypass diodes guarantee the modules free of overheating and Hot spot effect
Manufacturing facility certified by TUV Rheinland to ISO9001:2008
ISO14001:2004 and BS OHSAS 18001:2007
The Features of the solar cell
Homogeneours acid or caustic soda
Enhanced blu-ray spectral response
Silicon nitride antireflection coating
The Highest standards of the positive silver electrode
Silver aluminum negative electrode
Aluminum back surface field
Warranties
10-Year limited product warranty
Limited power warranty:10 years at 91.5% of the minimal rated power output
25 years at 81% of the minimal rated power output
In compliance with our warranty terms and conditions
Qualifications and Certificates
IEC61215.IEC61730.MCS.CE.ISO9001:2008.ISO14001:2004.BS OHSAS180012007.SA8000PV CYCLE
Electrical Performance
Electrical Parameter of at stand test condtions(STC) | |
Module type | MUL-6M-60M-36- |
Power output(W) | 60W |
Power output tolerances(w) | 0/5 |
Module efficiency % | 14.2 |
Voltage at Pmax V | 17.5V |
Current at Pmax A | 3.14A |
Open-Circuit Voltage(V) | 22.0V |
Short-Circuit current(A) | 3.30A |
STC:1000W/m² irradiance.25℃ Module temperature.AM1.5g spectrum according to EN60904-3.Averagae relative efficiency reduction of 5% at 200W/ m² according to EN60904-1
Thermal Characteristics | |
Nominal operating cell temperature | 45+-2℃ |
Temperature coefficient of Pmax | -0.45 |
Temperature coefficient of Voc | -0.33 |
Temperature coefficient of Isc | 0.06 |
Temperature coefficient of Vmpp | -0.45 |
Operating Conditions | |
Max.system voltage | 1000V DC |
Max series fuse rating | 15A |
Limiting reverse current | 15A |
Operating temperature range | -40℃ to 85℃ |
Max static load.front(e.g snow and wind) | 5400pa |
Max.static load.back(e.g wind) | 2400pa |
Max.hailstone impact(diameter/velocity) | 25mm/23m/s) |
Construction Materials | |
Front cover(material/thickness) | Low-iron tempered glass/4.0mm |
Cell(quantity/material/dimensions/number of busbars | 36/monocrystalline silicon/125mm×125mm/2 or 3 |
Encapsulant(material) | Ethylene vinyl acetate(EVA) |
Frame(material/color/anodizatin color/edge sealing | Anodized aluminum alloy/silver/clear/silicone or tape |
Junction box(protection degree) | ≥IP65 |
Cable(Length/cross-sectional area) | 1200mm /4 mm² |
Plug connector(type/protection degree) | MC4/IP67 |
General characteristics) | |
Dimensions(L/W/H) | 866x541x30 |
Weight | 7KG |
Packaging specifications | |
Package size | 1230×580×120mm |
Packing Configuration | 2 pcs/carton 28cartons/pallet |
Load capacity carton box | 666 pcs/20 ft container 1420 pcs/40ft container |
Due to continuous innovation.research and product improvement.the specifications in this product information sheet are subject ot change without prior notice.the specifications may deviate slightly and are not guaranteed.
The data do not refer to single module of contract and they are not part of the offer.they only serve for comparison to different module types
We supply sample for your testing.
We supply OEM & ODM
We can supply you the inverter according to your requirement
The warranty time is 2 years.
We are honor to supply our products to these countries
Company:Beijing Multifit Electrical Technology Co.,Ltd.
Company Address: 503 Building 5 No10 Ronghuanan road,Beijing Economic&Technological development Zone 100176,BeiJing China
Factory address:No.15 KeChuang street. Beijing Economic&Technological development Zone 100176,BeiJing China
Tel:86-010-87227420 Fax:86-10-85885278
Mobile No.:13641024477;15910870754
Website:
Company Profile:
Beijing Multifit Electrical Technology Co.. Ltd. is a high-tech plant for the solar power and renewable energy duction.sales and construction of photovoltaic power station.We located in the Chinese capital. the center of the Beijing Economic and Technological Development Zone - a beautiful high-tech Fortune 500 companies Industry park. Multifit group’s main products in Beijing plant are power inverter. micro-grid inverter. PV combiner box. solar controller. LED. Solar street lar modules. solar and wind power generation systems and other green energy products;we has another three branch plants in Guangdong province for the production of the solar lar portable lar water heater.EPS. UPS. Batteries.Battery d generator.Frequency Inverter.Softstarter. transformers etc.we undertake the projects related to electrical engineering design and installation also.Companies in strict accordance with the ISO9001: 2008 quality system. some products has the TUV.UL.CE.SONCAP. CCC and other international authoritative certification and national quality inspection certification. and the patents. Found in 2009. the company focused on providing world-class small-scale photovoltaic power plants for civilian solutions and innovative research and development of renewable energy electrical products. we had cultivated a group of ideals. experience. technical sales and R & D team. Products are now exported to France. UK. Italy.Hungary.Australia.Yemen.Pakistan.India.Nigeria.Dakar.Ghana.Chile. Dominican Republic Asia and Africa and Latin America.it is more than 50 countries and regions in the world.and meet the various needs of different regions ‘customers.we never stop to try our best to continue and enhance the customer’s satisfaction and awareness. Multifit name means to fit all your needs. step electric&energy technological mountain on new heights! The technological tie will be used to send you reach a higher level quality of life. Future. Multifit is committed to improving the renewable energy industry. and continues to develop more efficient and cost-effective solar solutions to bring more green electricity to our lives.
