Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > Hot Sell 10G BASE-SR SFP+ 850nm 300m Multi-Mode Optical Transceiver
Hot Sell 10G BASE-SR SFP+ 850nm 300m Multi-Mode Optical Transceiver
US$ 1 - 30
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Hubei, China
Brand Name:
MJ-SFP-10G85-3M-xx
Model Number:
SFP-10G85-3M-xx
Payment & Shipping
Payment Methods:
Port of Shipment:
Wuhan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MT41K256M16HA-125IT:E MICRONNegotiableMOQ: 1 Piece -
(IC Offer) ADUM1251ARZ-RL7US$ 0.01 - 10MOQ: 1 Piece
-
(HOT SALE) High Quality ic LS4148-GS08NegotiableMOQ: 1
-
1.25G 1470nm~1610nm CWDM GBIC 80km Single Mode Optical TransceiverUS$ 10 - 1,000MOQ: 1 Piece
-
1.25G 1310nmT/1490nmR BIDI GBIC 20km Single Mode Optical TransceiverUS$ 10 - 1,000MOQ: 1 Piece
Place of Origin
Hubei, China
Brand Name
MJ-SFP-10G85-3M-xx
Model Number
SFP-10G85-3M-xx
SFP-10G85-3M-xx
The SFP-10G85-3M-xx 10gbps 10gbase-sr MMF multi-mode 850nm 300m transceiver is SFP+ module for duplex optical data communications such as 10GBASE-SR and 10GBASE-SW. It is with the SFP+ 20-pin connector to allow hot plug capability. Digital diagnostic functions are available via an I2C. 10gbase-sr SFP module is designed for multi-mode fiber and operates at a nominal wavelength of 850 nm.The transmitter section uses a Vertical Cavity Surface Emitted Laser (VCSEL) and is a Class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated GaAs detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.
Key Features
Operating data rate up to 10.3Gbps850nm VCSEL TransmitterAverage Output Power:-6~-1dBmReceiver Sensitivity:-11.1dBmDistance up to 300m @50 / 125 um MMFSingle 3.3V Power supply and TTL Logic InterfaceDuplex LC Connector Interface, Hot PluggableCompliant with MSA SFP+ Specification SFF-8431Compliant with IEEE 802.3ae 10GBASE-SR/SWPower Dissipation < 1.0WDispersion tolerance up to 40ps/nm over G.651Built-in Digital Diagnostic Function
Applications
10GBASE-SW at 9.953Gbps10GBASE-SR at 10.3125GbpsOBSAI rates 6.144 Gb/s, 3.072 Gb/s, 1.536 Gb/s, 0.768Gb/sCPRI rates 9.830 Gb/s,7.373Gb/s, 6.144 Gb/s, 4.915 Gb/s, 2.458 Gb/s, 1.229 Gb/s, 0.614Gb/sOther Optical Link
Ordering Information
NotesX means LC or SC connector.xx means compatible brand. (For example: CO= Cisco, JU=Juniper, FD=Foundry, EX=Extreme, NE=Netgear. The two characters are short for compatible brand.)
Packaging
Antistatic bagPacked on pallets in a box(Default Customer Options)Specific Labels as RequestSeperate white Box for each transceiver
OEM and ODM
Combining our extensive design and engineering capability in optical transceiver industry, with our competitive advantages from integrated manufacturing capability, internal supply chain, and cost competitive and scalable operation infrastructure, Mingjia provides OEM, ODM, and contract manufacturing service to world leading customers with our manufacturing facilities in China.We are also mainly engaged in providing complete sets of optoelectronic device solutions to gain more brand extensions and influence in the world.
OEM/ODM order is availableWe can supply SFP-10G85-3M-xx according to your requirements, and design SFP-10G85-3M-xx label and packaging for your company.We welcome any inquiry for customized SFP+ optical transceiver.
