Portable PV Power System
Specifications & Features:
1. Battery capacity power display.
2. With 1* 5V USB & 3*12V DC output.
3. AC and DC two way output.
4. The system's battery can be charged by solar panels or national grid.
5. LED indicator for the working condition of charging and discharging
6. System suitable for household lighting, TV, fan, radio, computer and so on.
7. Reverse polarity connection protection
8. Reverse discharge protection
9. Over charge protection
10. Overloading protection
11. Overheat protection
12. Short circuit protection
13. Over voltage protection
14. Low-voltage protection
15. CE and Rohs certificates accredited.
Model | MSS150F | MSS300Z | MSS500Z-D |
Specifications | |||
Rated Output Power | 150W | 300W | 500W |
Solar Panel Power | 18V 50W(50W*1) | 18V 100W(50W*2) | 18V 100W(50W*2) |
Solar Panel Charging Time | 5.5 hours effective sunlight | 3 hours effective sunlight | 3 hours effective sunlight |
Battery Capacity | 12V 33Ah lead acid battery | 12V 33Ah lead acid battery | 12V 33Ah lead acid battery |
AC Output | AC 110V/220V/230V 50/60Hz | ||
AC Output Waveform | Modified sine wave | Pure sine wave | |
AC Output Socket | English/German/French/Australian/American/Universal | ||
Output Interface | 3*12V DC output & 1*5V USB | ||
Peak Inverter Efficiency | 85% | 92% | 92% |
Overload Protection | Yes | Yes | Yes |
Under-voltage Alarm | Yes | Yes | Yes |
Overheat Protection | Yes | Yes | Yes |
Short-circuit Protection | Yes | Yes | Yes |
Battery Power Indicator | Yes | Yes | Yes |
External Battery Charger | Yes | Yes | Yes |
External Battery | Yes(12V lead acid) | Yes(12V lead acid) | Yes(12V lead acid) |
External Battery Capacity | Based on actual needs and to be prepared by customer, the capacity of charging is more than or equivalent to the sum capacity of both our product and external battery. | ||
Accessories(Optional) | PV connectors 2 pairs | ||
External battery cables 2pcs | |||
Certificate | CE & RoHS | ||
Mechanical Data | |||
Dimensions of System Box(mm) | L375*W150*H320 | L375*W150*H320 | L375*W150*H320 |
Net Weight of System Box(kg) | 15.70 | 15.90 | 16.50 |
Appearance Color | White + Green | White + Green | White + Green |
Dimensions of Solar Panel(mm) | L640*W530*H30 | L640*W530*H30 × 2 | L640*W530*H30 × 2 |
Net Weight of Solar Panel(kg) | 4.50 | 10.50 | 10.50 |
Dimensions of Battery(mm) | L195*W130*H156 (Total H179) | L195*W130*H156 (Total H179) | L195*W130*H156 (Total H179) |
Net Weight of Battery(kg) | 10.50 | 10.50 | 10.50 |
