Specifications
Fluidized bed granulator
1, Uniform and porous particle
2,Continuous processing
3,meet the 'GMP'requirement
Pharmaceutical industry: tablet, capsule, low sugar or no sugar granule of Chinese medicine.
Foodstuff: cocoa, coffee, milk powder, juice of granulate, flavoring and so on
Other industries: pesticide, feed chemical fertilizer, pigment, dyestuff and so on
Drying: powder or granule material
Coating: granule, protecting coat of pellet, spare color, slow release film, bowel dissolve coating, etc.
Principle of Chemical industry fluid bed granulator
The Powder granule the container (fluidization bed)appear the state of fluidization. It is preheated and mixed with clean and heated air. At the same the solution of adhesive solvent is fogged and sprayed into the container. It makes the Same particles become granulating that contains adhesive. Being of unceasing dry through hot air, the moisture in the granulating is evaporated and the adhesive is solidification. The process is carried out continuously. Finally it forms ideal, uniform and porous granules.
Features of Chemical industry fluid bed granulator
Because of powder granulating, the flow property is improved and the dust is reduced.
Because of powder granulating, its solving property is improved.
The mixing, Granulating and drying can be completed in one step inside the machine.
The operation of equipment is safe because the anti-static filtering cloth is adapted.
The operation people won’t be hurt if an explosion take place because of releasing hole.
There is no dead angle, therefore the loading and unloading are quick and clean, it can meet the requirements of GMP.
pelletizer
