Scope of application of QG,JG Air Flow Dryer:
The equipment s wide used for drying powder, granule raw materials in foodstuff industry, chemical industry, pharmaceutical industry, construction materials industry, etc. The products that had been used the equipment are as follows: starch, glucose, fish powder, sugar, less, feedstuff, gluten, plastic resin, coal powder, dyestuff, etc.
Principle of QG,JG Air Flow Dryer:
The working principle of FG series drier is that the dry of damp raw material will be finished in two steps. First the raw material will be carried the first grade positive pressure dry through the tail air of the second dry and supplement hot air. The used tail air with high temperature and low damp will be exhausted. The semi-finished product will be dried the second grade negative dry through fresh hot air. The dried finished product will be packaged through measure. The used tail air with high temperature and low damp will be used for the first grade dry. In this way the good cycle dry process will be finished. The supplemental hot air amount can be adjusted freely in accordance with needs. So the machine has wide adaptability.
Technical parameters of QG,JG Air Flow Dryer:
| model | evaporated water(KG/H) | power(kw) | occupied area(m2) | thermal efficiency(%) |
| FG0.25 | 113 | 11 | 3.5×2.5 | >70 |
| FG0.5 | 225 | 18.5 | 7×5 | >70 |
| FG0.9 | 450 | 30 | 7×6.5 | >70 |
| FG1.5 | 675 | 50 | 8×7 | >70 |
| FG2.0 | 900 | 75 | 11×7 | >70 |
| FG2.5 | 1125 | 90 | 12×8 | >70 |
| FG3.0 | 1150 | 110 | 14×10 | >70 |
